This chapter provides the following information:
2.1

Introduction

Thank you for purchasing AT510x DC Resistance Meter.
AT510x is a high-precision wide-range, high-performance microprocessor-controlled
resistance meter. Its measurement range of 1 ～
30000. Test speed of 15 times / sec, it still can guarantee high test accuracy, and reading
can be controlled beating 3 words or less. It is unique to the current modes of three tests to
adapt different requirements. Sorting equipment with professional features, with a group
of stored data, various sorting information ring settings, can also be equipped with
Handler interface, used in automatic sorting system to complete fully automatic
production line testing. And an optional RS232C interface or IEEE-488 interface for
remote control, data acquisition and analysis.
Computer remote control commands compatible with SCPI (Standard Command for
Programmable Instrument Programmable Instruments standard command set), complete
and efficient remote control and data acquisition functions.
AT510x measures of high, medium and low-value resistor; various switch contact
resistance; connector contact resistance; relay line package and the contact resistance;
transformers, inductors, motors, deflection coil winding resistance; wire resistance; cars,
boats, aircraft riveting metal resistance; printed version of the line and pore of resistance
and so on.
2.2 Models Introduction

Full AT510x specifications are included in Appendix A.
2.3 Main Specification
AT510x technical specifications, including the basic technical specifications of the
instrument and equipment testing allows. These specifications are in the instrument
factory can achieve.

 Index


Models Introduction



Main Specification


Feature Overview
Model
AT510PRO
AT510
AT510SE
AT510L
AT510M
Detailed technical specifications see Appendix A.
Ω 20MΩ, the maximum display number
Resistance Range Accuracy
0.05%
1Ω-20MΩ
0.05%
1Ω-3MΩ
0.05%
10Ω-300kΩ
0.1%
1Ω-30kΩ
0.1%
100Ω-20M
9
