UDP Incoming UDP network messages
TCP Incoming TCP network messages
OSC Incoming OSC network message
DMX Input DMX received on one or more of the DMX ports (switch
port to input in the settings page)
Art-Net Incoming Art-Net DMX data
sACN Incoming sACN DMX data
Timecode Timecode signal, specify the incoming timecode protocol on
the Settings page.
Kiosc Triggers from Kiosc. For each Action various controls can
be chosen such as buttons and sliders, colour picker etc. The
order of the actions will control the arrangement in Kiosc.
Scheduler Triggers based on time, date, weekdays, sunrise, sunset &
timespan.
Playback Events generated by the playbacks
Randomiser The randomiser can generate a random number
System Events such as 'Start up'
Variable The Variable source works in combination with the variable
task (For more information about the Variable task please
refer to Task Types). The Variable task will set a value of
which an enabled actionlist type with Variable as Source
will use as a trigger. The QuadCore will keep the values of
the 10 variables even after shut down so long as the RTC
battery is not empty.
Timer There are 4 internal timers in the QuadCore. An event will
be raised when a timer expires. Timers are set and
activated by the Timer tasks.
Actionlist Gives an event when an actionlist is enabled or disabled.
User List 1-4 These actionlists will never trigger an event, however, they
are useful for advanced programming.
Actionlists can be temporarily suspended by disabling their checkbox in the
Show Control page. There is also a task available to automate changing the
state of this checkbox.
9.2 Actions
Actions are executed when a certain signal is received. This signal is defined by
the trigger. A trigger is always relative to the action-list the action belongs to.
For example, when the trigger-type is set to 'Channel' then it refers to a single
DMX channel if the action is placed inside a 'DMX Input' list and it means a
