Visual Productions QuadCore Manual page 100

Feature Function
Universe Control HTP
Universe Clear
Channel Set
Channel Toggle
Channel Control
Channel Inverted Control
Channel Decrement
Channel Increment
Bump Set
Bump Control
Clear All
RGB Set
RGB Control
RGBW Control
XY Control
XxYy Control
Ii Set
Ii Control
Block Control
Block RGBW Control
Block CW Control
Block CW Inverted Control
The Bump feature will momentarily set the value of a DMX channel and then
take it back to 0, effectively creating a pulse.
XY will take an incoming position and translate it to two DMX channels. XxYy
will translate it to four DMX channels; a 16-bit pan and a 16-bit tilt level.
The Ii feature can take an incoming value and translate it to two-channel DMX
16-bit value.
Block can set a number of DMX channels to the same value. Parameter 1 will
denote the starting channel and parameter 2 determines how many channels will
be set. The footprint field in parameter 1 offers the possibility to have 'space'
between the channels.
The Block RGBW feature is similar to the normal Block. The difference is that
Parameter 1
Universe #
Universe #
DMX Channel
DMX Channel
DMX Channel
DMX Channel
DMX Channel
DMX Channel
DMX Channel
DMX Channel
-
DMX Address
DMX Address
DMX Address
DMX Address
DMX Address
DMX Address
DMX Address
DMX address and footprint
DMX address and footprint
DMX address and footprint
DMX address and footprint
100
Parameter 2
-
-
DMX Value
-
-
-
-
-
DMX Value
-
-
RGB Colour Value
-
-
-
-
Intensity Value
-
Fixture count
Fixture count
Fixture count
Fixture count
