Visual Productions QuadCore Manual page 28

1. Connect to the network
Connect the QuadCore with an Ethernet cable to the router.
required that the network is managed by a router that features a DHCP
server. If the network router is not DHCP capable then read the network
chapter on page 32 for alternative setups.
2. Configuring the Art-Net input
Go to the Settings page and set the desired Art-Net universes for port A
and B at Sub.Uni A and Sub.Uni B The QuadCore counts the Art-Net
universes from 0.0. For example, Art-Net universe 1 is at 0.0, Art-Net
universe 16 is at 0.15 and Art-Net universe 17 is at 1.0. It is also possible
to enter the Art-Net universe number (0, 16 or 17 for example) and the
QuadCore will automatically convert the value to a valid format.
3. Configure port settings
Go to the Settings page and set DMX Port A to Universe A and Port B
to Universe B.
28
It is
