Visual Productions QuadCore Manual page 108

URI
/core/va/1/set
/core/va/1/refresh
/core/va/refresh
The following table shows how to active miscellaneous functions.
URI Parameter
/core/dmx/1 integer
/core/blink -
/core/hello -
D.2 TCP & UDP
TCP (Transmission Control Protocol) is a protocol for sending messages across
an Ethernet network. TCP provides reliable, ordered and error-checked delivery
of messages between programs running on computers connected to a local area
network, intranet or the public Internet.
UDP (User Datagram Protocol) is a simple protocol for sending message across
the network. It does not provide any error checking. Although UDP is a bit
faster than TCP, it is less secure.
Typically either TCP or UDP is supported by various media devices like video
projectors and show controllers.
The functionality within the QuadCore can controlled by using the following
ASCII strings (human readable text) messages:
The following table uses playback #1 as an example. The number '1' can be
replaced by any number in the range of [1,6].
Parameter Description
integer Set the value of variable #1
- Refresh variable #1; a trigger will be generated as if the
variable changed value
- Refresh all variables; triggers will be generated
Description
Set the value of a DMX channel
Momentarily flashes the QuadCore's LED
The unit will reply with the same Hello message
