Visual Productions QuadCore Manual page 111

D.3
HTTP (Hyper Text Transfer Protocol) is the standard protocol to access web
pages. It can also be used to control the QuadCore, using the URLs listed below.
The following table uses playback #1 as an example. The number '01' can be
replaced by any number in the range of [01,06].
Description
Playback Go Forward
Playback Go Back
Playback Jump
Release playback
Set playback intensity
Set playback rate
Release all playbacks
Set master intensity
Set master rate
Set master fade
Start a solo playback
Description
Record a snapshot of DMX
Record a snapshot of Art-Net
Record a snapshot of sACN
The following table uses actionlist #1 as an example. The number '01' can be
replaced by any number in the range of [01,08].
String
core-dmx-1= integer
core-blink
core-hello
HTTP
URL
/ajax/pbXX/go+
/ajax/pbXX/go-
/ajax/pbXX/jmp
/ajax/pbXX/rel
/ajax/pbXX/int
/ajax/pbXX/rat
/ajax/rel
/ajax/int
/ajax/rat
/ajax/fad
/ajax/pb/sol
URL
/ajax/tr/snapshot/dmx
/ajax/tr/snapshot/dmx
/ajax/tr/snapshot/dmx
Description
Set the value of a DMX channel
Momentarily flashes the QuadCore's LED
The unit will reply with the same Hello message
Parameter Range Example
- http://192.168.1.10/ajax/pb01/go+
- http://192.168.1.10/ajax/pb01/go-
[1, 32] http://192.168.1.10/ajax/pb01/jump
- http://192.168.1.10/ajax/pb01/release
[0.0, 1.0] http://192.168.1.10/ajax/pb01/intensity=0.55
[-1.0, 1.0] http://192.168.1.10/ajax/pb01/rate=0.55
- http://192.168.1.10/ajax/release
[0.0, 1.0] http://192.168.1.10/ajax/intensity=0.55
[-1.0, 1.0] http://192.168.1.10/ajax/rate=0.55
text http://192.168.1.10/ajax/fade=3s
[1, 6] http://192.168.1.10/ajax/pb/sol=3
Parameter Range
-
-
-
111
Example
http://192.168.1.10/ajax/track/snapshot/dmx
http://192.168.1.10/ajax/track/snapshot/artnet
http://192.168.1.10/ajax/track/snapshot/sacn
