Description URL
Execute action /ajax/alXX/2/exe
Enable actionlist /ajax/alXX/ena
Description
Blink LED
You can send your HTTP GET requests to port 80.
D.4
The QuadCore is able to send feedback to external equipment using its API, so
called 'clients'. The QuadCore keeps a memory of the last four OSC clients and
last four UDP clients. The clients will automatically receive updates on several
playback related state changes.
Below is a table listing the messages the QuadCore will send back to its clients.
OSC
/core/pb/1/intensity
/core/pb/1/rate
/core/pb/intensity
/core/pb/rate
/core/pb/fade
/core/pb/1/active
/core/pb/1/cue
/core/al/1/enable
/core/hello
The hello command is ideal for polling the device; it allows you to verify that
the QuadCore is online at the IP address and port that you expect.
A power-cycle will clear the internal client lists. Send /core/goodbye or core-goodbye
to explicitly be removed from the list.
Consider programming custom action in the show control when additional feed-
back functionality is required.
Parameter Range
-
true/false
URL Parameter Range
/ajax/bli -
Feedback
UDP
core-pb-1-intensity
core-pb-1-rate
core-pb-intensity
core-pb-rate
core-pb-fade
core-pb-1-active
core-pb-1-cue
core-al-1-enable
core-hello
Example
http://192.168.1.10/ajax/al01/2/exe=true
http://192.168.1.10/ajax/al01/enable=false
Example
http://192.168.1.10/ajax/blink
