Binary Inputs (BI)

NPT NPA UNIT
BI 1 -
BI 2 -
BI 3 -
BI 4 -
BI 5 -
BI 6 -
BI 7 -
BI 8 -
BI 9 -
BI 10 -
BI 11 -
BI 12 -
13 -
BI 14 -
BI 15 -
BI 16 -
BI 17 -
BI 18 -
BI 19 -
BI 20 -
BI 21 -
BI 22 -
BI 23 -
BI 24 -
BI 25 -
BI 26 -
BI 27 -
BI 28 -
BI 29 -
BI 30 -
BI 31 -
The values in bold are default values.
MG.90.C1.02 - VLT is a registered Danfoss trademark
Description
Thermal warning status
Current limit status
Voltage warning status
Ramping
Motor running status
Frequency status
Control status
Reference status
Warning status
Tripped status
Coasting stop status
Drive ready status
Drive control status
Heat sink temperature high
Switch mode warning
Terminal 33
Terminal 29
Terminal 27
Terminal 19
Terminal 18
Output frequency low
Output frequency high
Output current low
Reserved
Out of frequency range
Output current high
Feedback low
Feedback high
Reserved
Reserved
Live zero error
Appendix A
VLT ® 2800 Metasys N2
Range
0=OK, 1=Limit
0=OK, 1=Limit
0=OK, 1=Limit
0=FALSE, 1=TRUE
0=Not Running,
1=Running
0=Out of Range,
1=In Range
0=Local, 1=Bus
0=Not on Ref.,
1=On Ref.
0=No Warning,
1= Warning
0=No Trip, 1=Tripped
0=Not Enabled,
1=Enabled
0=Not Ready,
1=Ready
0=Not Ready,
1=Ready
0=OK, 1=Warning
0=OK, 1=Warning
0=NO SIGNAL,
1=Signal
0=NO SIGNAL,
1=Signal
0=NO SIGNAL,
1=Signal
0=NO SIGNAL,
1=Signal
0=NO SIGNAL,
1=Signal
0=FALSE, 1=TRUE
0=Remote ref.,
1=Local ref.
0=FALSE, 1=TRUE
0=OK, 1=Warning
0=FALSE, 1=TRUE
0=FALSE, 1=TRUE
0=FALSE, 1=TRUE
0=OK, 1=Warning
VLT 2800 PNU
534
534
534
541
534
534
534
534
534
534
534
534
534
540
540
528
528
528
528
528
541
541
541
540
541
541
541
540
19
