FIRST TEAM SPORTS Vector Series Assembly Instructions

FIRST TEAM SPORTS, INC
Vector Series Assembly Instructions

Bill of Materials

(1) Vertical Post
(1) Extension Arm Support Channel
(2) Upper Extension Arms
(2) Lower Extension Arms
(1) Adjustment Crank
(2) Lift Springs
(1) Rim Height Indicator
(1) H-Frame Backboard Support
NOTE: Immediately unpack all components and cross check against bill of materials. Report
(2) 1/2" x 4" Square U-Bolt
(4) 1/2" Flatwasher
(4) 1/2" Lockwasher
(4) 1/2" Hex Nut
(4) 1/2" x 12" Hex Bolt
(5) 1/2" Centerlock Nut
(8) 1/2" Nylon Flatwasher
(1) 1/2" x 13" Hex Bolt
(4) 5/16" x 1" Machine Screw
(4) 5/16" Flatwasher
(4) 5/16" Lockwasher
(4) 5/16" Hex Nut
(1) Set of Height Stickers
(1) Post Cap
(1) Anti-Seize Lubricant
(1) Adjustment Handle
