3.1.2

J1 Connector Legend

Signal Name
U_CMMD
AIn
AIHn
AILn
DIn
DOn
ExtTimeBase
ExtTrg
SSH_OUT
GP_TC_CLK
GP_TC_GATE
GP_TC_UPDN
GP_TC_OUT
+5V OUT
+15V OUT
-15V OUT
AGND
DGND
N/C

3.2 Analog Input Signal Connection

The cPCI-9116 series provides up to 64 single-ended or 32 differ-
ential analog input channels. You can set and fill the channel gain
queue to get the desired combination of the input signal types. The
analog signals can be converted to digital values by the A/D con-
verter. To avoid ground loops and to obtain accurate measure-
ments from the A/D conversion, it is important to understand the
signal source type and how to choose the analog input modes:
Single-ended, Differential, or User Common Mode.
Signal Connections
Definition
User Common Mode
Analog Input Channel n (single-ended)
Analog High Input Channel n (differential)
Analog Low Input Channel n (differential)
Digital Input Signal Channel n
Digital Output Signal Channel n
External Timebase Clock Input
External Digital Trigger Signal
SSH Output Signal
General Purpose Timer/Counter Clock Input
General Purpose Timer/Counter Gate Input
Purpose Timer/Counter Up/Down Control Input (0:down, 1:up)
General Purpose Timer/Counter Output
+5V Output
+15V Output
-15V Output
Analog Ground
Digital Ground
No Connection
Table 3-1: J1 Connector Legend
cPCI-9116
15
