Summary of Contents for ADLINK Technology cPCIS-ET2600 Series
- Page 1 Series 4U Height Wide Temperature Range Subsystem for 3U CompactPCI Modules User’s Guide This datasheet has been downloaded from http://www.digchip.com at this page...
- Page 2 Copyright 2013 ADLINK Technology, Inc. All Rights Reserved. Manual Rev. 1.00, January 2, 2013 Part No.: 50-15088-2000 The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.
-
Page 3: Table Of Contents
Pin Assignment..............24 cBP-3062 Power Backplane............27 Specifications ..............27 Mechanical Drawing ............27 Pin Assignment..............28 Cooling System ................31 Removing and Replacing the Air Filters cPCIS-ET2600 Series models with CompactPCI PSU(s) .............31 Fan Alarm: Fan Removal and Replacement ......33 Table of Contents • iii... - Page 4 Temperature Alarm..............34 Fan Specifications ..............34 Mechanical Drawing ............34 Power Supply Unit ...............35 CompactPCI: cPS-P325/AC ............35 Features ................35 Specifications ..............35 Input Characteristics............36 Output Characteristics ............36 Specifications ................39 Features...................39 Mechanical................39 Environmental................40 System Alarm Board..............40 Important Safety Instructions ...........43 Getting Service ................45 iv • Table of Contents...
-
Page 5: How To Use This Manual
How to Use This Manual This manual is designed to help you use the cPCIS-ET2600 series 3U CompactPCI Subsystem . It is divided into six chapters: Chapter 1: Introduction, gives an overview of the product features. Chapter 2: Getting Started, describes the unpacking procedure, setup and configuration of the subsystem . - Page 6 This page intentionally left blank. vi • Introduction...
-
Page 7: Introduction
Introduction Product Definition The cPCIS-ET2600 wide temperature range subsystem is rack mountable, 4U in height, and designed for 3U CompactPCI cards and modules. They are ideal for industrial or transport applications where small chassis size with multi-functionality are important, and provide maximum cooling efficiency, a guarded power on/off button, ample power capacity, a hot swap backplane and easy maintenance. -
Page 8: Mechanical Drawing
Mechanical Drawing 2 • Introduction... -
Page 9: Configurations
Configurations The cPCI-ET2600 Series comes in the following configuration: system peripheral PSU(s) monitor PICMG slots slots cPCIS- 250W cPCI — 2.0, 2.1, 2.11 ET2632[R] (1 + 1) *cPCIS-ET2632 is available with rear I/O backplanes for Rear Transition Modules (RTMs) and is indicated by an “R” suffix on the model name. Customized Systems Subsystem s can also be customized to meet individual needs. - Page 10 This page intentionally left blank. 4 • Introduction...
-
Page 11: Getting Started
In this chapter, we will describe the unpacking procedure of the subsystem and CompactPCI board and power supply unit (PSU) installation procedures for cPCIS-ET2600 Series models with CompactPCI PSU(s) only. Shipping Contents Check the shipping carton for any damage. If the shipping carton and contents are damaged, please notify the dealer for a replacement. - Page 12 PSU Slot System slots usually have obvious indicators (e.g. red card guide rail, triangle mark enclosing the slot number on the backplane, etc.) System cards can only be installed in a system slot. Do not insert a system card into any other slot, or insert any peripheral card into system slot.
- Page 13 The handle on CompactPCI cards and PSUs ensures simple and safe installation and removal. Please follow the procedures below to install a CompactPCI module into a cPCIS-ET2600 Series chassis with CompactPCI PSU(s): CompactPCI Card Installation/Removal Procedure Place the subsystem on a level surface or rackmount it. Remove the blanking plates where required by undoing the retaining screws at each end.
- Page 14 Fully Latched Handle Engages with Chassis System Card Fully Inserted To remove the module, press the release button (if necessary), and reverse steps 1 through 5 above. 8 • Backplane...
-
Page 15: Rtm (Rear Transition Module) Installation
PSUs are full range 90-240VAC and do not require input voltage setting. Insert a system module into the appropriate card slot. The cPCIS-ET2600 Series subsystems feature a guarded power switch. Use a suitably shaped object (such as a pen) to actuate the power switch. All LEDs will light up to indicate normal operating conditions. -
Page 16: Backplane
Backplane In this chapter, we will describe the backplane for the cPCIS-ET2600 Series subsystems. The following table specifies the backplane(s) that correspond to each model. power backplane slots backplane cPCIS-ET2632[R] cBP-3208[R] cBP-3062A cBP-3208[R] Backplane The cBP-3208[R] is a 3U CompactPCI 32-bit backplane with optional rear I/O (designated by an “R”... -
Page 17: Mechanical Drawing
Mechanical Drawing 8 - P2 1 - P2 8 - P1 1 - P1 cBP-3208[R] Front View Backplane • 11... - Page 18 1 - P2 Optional Rear I/O: 2 - P2 to 8 - P2 cBP-3208[R] Rear View 12 • Backplane...
-
Page 19: Pin Assignment
Pin Assignment [1 – P1] System Slot REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11] AD[10] +3.3V AD[15] AD[14] AD[13] SERR# +3.3V C/BE[1]# +3.3V IPMB_SCL IPMB_SDA PERR# DEVSEL# V(I/O) - Page 20 [1 – P2] System Slot CLK6 CLK5 PRST# REQ6# GNT6# DEG# FAL# REQ5# GNT5# V(I/O) CLK4 GNT3# REQ4# GNT4# CLK2 CLK3 GNT2# REQ3# CLK1 REQ1# GNT1# REQ2# 14 • Backplane...
- Page 21 [2 – P1] / [8 – P1] Peripheral Slot REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11] AD[10] +3.3V AD[15] AD[14] AD[13] SERR# +3.3V C/BE[1]# +3.3V IPMB_SCL IPMB_SDA PERR#...
- Page 22 CN1 / CN2 – ATX Power Connector Signal Signal +3.3V +3.3V +3.3V -12V PS_ON_L POWER GOOD 5V STB +12V JP7 – connector Pin # Signal Name +12V -12V Sense JP8 – connector Pin # Signal Name INH# JP9 – connector Pin # Signal Name PRST#...
-
Page 23: Cbp-3206[R] Backplane
cBP-3206[R] Backplane The cBP-3206[R] is a 3U CompactPCI 32-bit backplane with optional rear I/O (designated by an “R” suffix). The cPCIS-2642[R] uses two of these backplanes. Specifications • Standard CompactPCI height for 3U cPCI cards • CompactPCI Compliancy PICMG 2.0 CompactPCI core specification R3.0 PICMG 2.1 CompactPCI hot swap R2.0 •... -
Page 24: Mechanical Drawing
Mechanical Drawing 6 - P2 1 - P2 6 - P1 1 - P1 cBP-3206[R] Front View JP8 - JP10 1 - P2 Opt. Rear I/O: 2 - P2 to 6 - P2 cBP-3206[R] Rear View 18 • Backplane... -
Page 25: Pin Assignment
Pin Assignment [1 – P1] System Slot REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11] AD[10] +3.3V AD[15] AD[14] AD[13] SERR# +3.3V C/BE[1]# +3.3V IPMB_SCL IPMB_SDA PERR# DEVSEL# V(I/O) - Page 26 [1 – P2] System Slot CLK6 CLK5 PRST# REQ6# GNT6# DEG# FAL# REQ5# GNT5# V(I/O) CLK4 GNT3# REQ4# GNT4# CLK2 CLK3 GNT2# REQ3# CLK1 REQ1# GNT1# REQ2# 20 • Backplane...
- Page 27 [2 – P1] – [6 – P1] Peripheral Slot REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11] AD[10] +3.3V AD[15] AD[14] AD[13] SERR# +3.3V C/BE[1]# +3.3V IPMB_SCL IPMB_SDA PERR#...
- Page 28 CN1 / CN2 – ATX Power Connector Signal Signal +3.3V +3.3V +3.3V -12V PS_ON_L POWER GOOD 5V STB +12V JP8 – connector Pin # Signal Name INH# -12V Sense JP9 – connector Pin # Signal Name PRST# JP10 – connector Pin # Signal Name FAL#...
-
Page 29: Cbp-3061 Power Backplane
cBP-3061 Power Backplane The cBP-3061 is a PICMG 2.11 CompactPCI 3U 47-pin power backplane for one power module. It is used by the cPCIS-2631/2642[R]. Specifications • CompactPCI Compliancy: PICMG 2.11 CompactPCI Power Interface • Dimensions: 40.64x 128.7 mm • Power Module Sockets: one •... -
Page 30: Pin Assignment
Pin Assignment CN1 – Power Sense Connector Pin # Signal Name V1_Sense GND_S V2_Sense V3_Sense CN2 – Power Sense Connector Pin # Signal Name V1_Sense GND_S V2_Sense V3_Sense CN3 – connector Pin # Signal Name INHJ 24 • Backplane... - Page 31 CN4 – Modular Power 47P Connector Signal Signal ACL/-DC IN ACN/+DC IN V1 SENSE CGND V1ADJ V3 SHARE IPMB_PWR +FAL# RESERVED V2 SHARE IPMB_SDA INH# RESERVED DEG# IPMB_SCL V3 SENSE V1 SHARE S RTN 13-18 V2 SENSE 5-12 V2ADJ CN5 – Current Share Connector Pin # Signal Name V1_Share...
- Page 32 CN7 –AC/DC in Let Connector Pin # Signal Name ACN/DC+ ACL/DC- CGND CN8 – IPMB Connector Pin # Signal Name IPMB_SCL IPMB_SDA IPMB_PWR ALERT CN9 – ATX Power Connector Signal Signal +3.3V +3.3V +3.3V -12V PS_ON_L POWER GOOD 5V STB +12V 26 •...
-
Page 33: Cbp-3062 Power Backplane
cBP-3062 Power Backplane The cBP-3062 is a PICMG 2.11 CompactPCI 3U 47-pin power backplane for two power modules. It is used by the cPCIS-ET2632[R]. Specifications • CompactPCI Compliancy: PICMG 2.11 CompactPCI Power Interface • Dimensions: 40.64x 128.7 mm • Power Module Sockets: two •... -
Page 34: Pin Assignment
cBP-3062[R] Front View cBP-3062[R] Rear View Pin Assignment CN1 / CN2 – Modular Power 47P Connector Signal Signal ACL/-DC IN ACN/+DC IN V1 SENSE CGND V1ADJ V3 SHARE IPMB_PWR +FAL# RESERVED V2 SHARE IPMB_SDA INH# RESERVED DEG# IPMB_SCL V3 SENSE V1 SHARE S RTN 13-18... - Page 35 CN5 – Power Sense Connector Pin # Signal Name V1_Sense GND_S V2_Sense V3_Sense CN6 –Connector Pin # Signal Name IPMB_SCL IPMB_DA IPMB_PWR ALERT CN7 – Current Share Connector Pin # Signal Name V1CS GND_S V2 CS V3 CS CN8 – Current Share Connector Pin # Signal Name V1 CS...
- Page 36 CN9 / CN10 – ATX Power Connector Signal Signal +3.3V +3.3V +3.3V -12V PS_ON_L POWER GOOD 5V STB +12V JP1 – connector Pin # Signal Name INH#2 JP2 – connector Pin # Signal Name INH#1 JP3 – connector Pin # Signal Name DEG#1 FAL#1...
-
Page 37: Cooling System
Removing and Replacing the Air Filters cPCIS-ET2600 Series models with CompactPCI PSU(s) To ensure proper performance, the air filters of cPCIS-ET2600 Series subsystems with CompactPCI PSUs should be cleaned or replaced as necessary. Replacement air filters are supplied and can be found in the Accessory Packet. - Page 38 After cleaning or replacing the filter, place it back in position and re- attach the filter cover. Remove the screws attaching the bottom filter cover on the bottom of the chassis (6 screws – see diagram below). After cleaning or replacing the filter, place it back in position and re- attach the filter cover.
-
Page 39: Fan Alarm: Fan Removal And Replacement
Fan Alarm: Fan Removal and Replacement The embedded alarm board monitors temperature & fan status. Should a fan become disabled, the Alarm LED will light up and an audible warning will be heard. The LED corresponding to the faulty fan will flash, indicating which fan needs to be replaced. -
Page 40: Temperature Alarm
Temperature Alarm When the subsystem's internal temperature exceeds 50°C, the TEMP LED will flash and an audible warning will be heard. To reset the alarm and disable the audible warning, press the Alarm RST button. In order to protect the system from damage resulting from overheating, it should be shut down immediately. -
Page 41: Power Supply Unit
Power Supply Unit The cPCIS-ET2600 Series subsystems are equipped with ADLINK’s cPS- P325/AC CompactPCI power module. CompactPCI: cPS-P325/AC Features • 250W 3U X 8HP Eurocard package • Meets EN 61000-3-2 active power factor correction • Internal OR-ing diodes for N+1 redundancy •... -
Page 42: Input Characteristics
Input Characteristics • Input Voltage: Typ. 90-264VAC • Power Factor Correction: Meets Harmonic Correction EN 61000-3-2. • Input Connector: CompactPCI 47-pin power connector • Input Frequency: 47-63Hz • Inrush Current: Less than 15A@240VAC • Input Current: 3.6A@230VAC/ 4A@260VAC • EMI: Meets EN55022 / FCC Class A •... - Page 43 • Noise & Ripple: 60 mV@5V and 3.3V output; 120mV@.± 12V output. • OVP: Built-in at all outputs. • Adjustability: Available at VO1, 2 & 3. • Output Trim: Electrical trim available at VO1/VO2 [ADJ #]. • Remote Sensing: Available at VO1, VO2 & VO3. •...
- Page 44 This page intentionally left blank. 38 • Power Supply Unit...
-
Page 45: Specifications
Specifications Features • Standard 19” Rack-mount 3U CompactPCI form factor (4U height). • Board Space: Supports both front and rear access for I/O, CPU, and power supply. Standard 3U, 21-slot width chassis. • Five front-access hot swappable fans with removable air filter for self- cooling. -
Page 46: Environmental
Environmental • Operating Temperature: -20°C to 50°C (Supports operation up to 70°C but with derating above 50°C. Power efficiency will be derated by 2.5% for every degree Celsius with only 50% power efficiency at 70°C, i.e. 125W/PSU.) • Storage Temperature: -40 to 85°C. •... - Page 47 Mechanical Drawing Specifications • 41...
- Page 48 This page intentionally left blank. 42 • Specifications...
-
Page 49: Important Safety Instructions
Important Safety Instructions Read and follow all instructions marked on the product and in the documentation before you operate your system. Retain all safety and operating instructions for future use. Please read these safety instructions carefully. Please keep this User‘s Manual for later reference. The equipment can be operated at an ambient temperature of 50ºC. - Page 50 Lithium Battery provided (real time clock battery) “CAUTION – Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions” If one of the following situations arises, get the equipment checked by a service personnel: The power cord or plug is damaged.
-
Page 51: Getting Service
5215 Hellyer Avenue, #110, San Jose, CA 95138, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-360-0222 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. Address: 300 Fang Chun Rd., Zhangjiang Hi-Tech Park, Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com... - Page 52 84 Genting Lane #07-02A, Cityneon Design Centre, Singapore 349584 Tel: +65-6844-2261 Fax: +65-6844-2263 Email: singapore@adlinktech.com ADLINK Technology Singapore Pte. Ltd. (Indian Liaison Office) Address: 1st Floor, #50-56 (Between 16th/17th Cross) Margosa Plaza, Margosa Main Road, Malleswaram, Bangalore-560055, India Tel: +91-80-65605817, +91-80-42246107 Fax: +91-80- 23464606 Email: india@adlinktech.com...
