1.- VERIFICATION UPON RECEPTION
Check the following items on reception of the device:
a) The device meets the specifications described in your order.
b) The device has not suffered any damage during transport.
c) Perform an external visual inspection of the device prior to switching it on.
d) Check that it has been delivered with the following:
2.- PRODUCT DESCRIPTION
CVM-NET4+-MC is an instrument that measures and calculates the main electrical parameters of
three-phase (balanced or unbalanced) and single-phase industrial power networks.
It measures effective (RMS) values, using three alternating and neutral voltage inputs and can measure
up to 4 circuits with three current inputs (through current transformers In / 0.250 A) .
The device features:
- One button, used to restore the device's default communication parameters.
- 2 indicator LEDs: CPU and COMM�
- RS-485 communications, with the MODBUS RTU® protocol
- 4 digital relay outputs�
6
- An installation guide,
If any problem is noticed upon reception, immediately contact the transport com-
pany and/or CIRCUTOR's after-sales service.
