3�4�2�- 4 THREE-PHASE CHANNELS WITH MC1 and MC3
10
Figure 3: 4 three-phase channels with MC1 and MC3
D D D D D B S
01 02 03 04 D0
V V V V
Power Supply L1 L2 L3 N DIGITAL OUTPUTS COM RS485
CPU
COMM
RESET
Channel 1 Channel 2 Channel 3 Channel 4
1 2 3 C 1 2 3 C 1 2 3 C 1 2 3 C
S1 S1 S1 S2 S1 S1 S1 S2 S1 S1 S1 S2 S1 S1 S1 S2
CVM-NET4+-MC
A
Instruction Manual
