4�4�8�3�- Configuration of digital outputs
Digital outputs, in addition to being remotely managed, can be used as alarm elements, associated
with an electric variable by a maximum or minimum value, or can carry out the power impulse function
associated with any power consumption parameter (active or reactive).
The following input table is provided to programme them
Digital output 1
Modbus Address
Note: When a power variable is selected, the unit automatically recognises the power impulse function
and applies the w·h value of the first record. The pulse width value is in milliseconds
Example of alarm programming by maximum and minimum value with voltage VL1:
Programme a maximum value of 240 V and a minimum value of 200 V (the voltage value must be sent
multiplied by 10 (as shown in
Maximum value: 2400 (Decimal) → 00000960 (Hexadecimal)
Minimum value: 2000 (Decimal) → 000007D0 (Hexadecimal)
Delay: 10 (Decimal) → 000A (Hexadecimal)
Variable Number: 01 (Decimal) → 01 (Hex)
Write:
Read:
18
Table 14:Configuration of Channel 1 digital output
2AF8, 2AF9 MAX value or W•h imp
2AFA, 2AFB MIN value
2AFC Variable number
2AFD Delay / Pulse width
Table 22
TX: NP 10 2AF8 0006 0C 00000960 000007D0 000A 0010 CRC
RX: NP 10 2AF8 0006 CRC
TX: NP 04 04 2AF8 0006 CRC
RX: NP 04 0C 00000960 000007D0 000A 0010 CRC
Table 14
Variable
00 (See
, and .), and a delay of 10 s.
Table 23 Table 24
CVM-NET4+-MC
:
Valid data margin
Hexadecimal value
Hexadecimal value
Table 22,Table 23 and Table 24
0 to 270F (9999 Decimal)
