8 - Technical specifications
HC 5500 Function
Opt 1 Pressure sensor
Opt 2 RPM sensor or anemometer
Speed
Flow
L end nozzle Pendulum lock at HAY/LPY
R endnozzle Pendulum lock at HAY/LPY
Reg (Yellow)
Bypass EC on/off
Sec 9 User defined A&B 2
Sec 8 User defined A&B 1
Sec 7 Twin speed
Sec 6 Twin angle
Sec 5
Sec 4
Sec 3
Sec 2
Sec 1
Foam marker No. 4 Not used

Plug positions for HZ hydraulics

1. Fold left
2. Fold left
3. Tilt left down
4. Tilt left up
5. Tilt right down
6. Tilt right up
7. Fold right
8. Fold right
9. (B) flow reverse
10. (A) flow forward

Road traffic lights

The wiring is in accordance with ANSI/ASAE S279.11.
Position
1. Ground
2. Work lamps
3. LH flashing & turn indicator
4. Free
5. RH flashing & turn indicator
6. Free
7. Free
8.8
Gnd
2
Wire color
White
Black
Yellow
Red
Green
Brown
Blue
+ Sig.
Brn Blu
Brn Blu
Brn Blu
Brn Blu
Brn
Brn
Brn
Brn
x
x
Brn
Yel
Brn
Brn
Brn
Brn
Brn
L R
6 5
-
-
Blk
Blk
Blk
Blu
Blu
Blu
Blu
x
x
Whi
Gre
Blu
Blu
Blu
Blu
Blu
- +
1 3
