In matrix mode, any operations are unavailable except signal selection, bank selection,
alpha
time and black scene setting.
Default source 1 to monitor 1, source 2 to monitor 2, and so on. Select the signal, and
drag it to the source that will set. For example, set signal 9 for source 1, as shown in the
figure below:
Note: Click the monitor (the border of the monitor will turn to red), then double click the
signal (the border of the monitor will turn to yellow), the signal will be switched to the
monitor.
Source 1 will be switched to signal 2, click source 1, then click "Take" icon , the
signal will be switched to the corresponding monitor. Connect the signal to the
corresponding output after setting.
Preview Mode
Click the "Preview Mode", and pop-up window as follows:
Click "OK", the system will synchronize the data, and it will finish about 5 seconds later,
click "OK", it will enter the interface as follows:
