RGBlink X3 User Manual page 35

Click the EDID shortcut " ", and pop-up window as follows:
The special display project or LED display application would like to require special
resolution settings to meet the requirement. Select the input or output board to read and
write the EDID. As shown in the figure below:
If select the 4K input card, as shown in the figure below:
Click the input port, and set the width, height and frequency. Click "Set" after setting.
Select "Reset", all the setting will be recover to factory setting.
X3 User Manual
34
