ADLINK Technology cPCI-6880 Series User Manual page 9

cPCI-R6000-NF Board Layout
CN10 CN1
CN5
U31
CN12
U26
U31
JP1
CN1/2
CN5
CN9
CN10
cPCI-R6000-NF Connector Pin Assignment
rJ3
JP1
SW1 SW3
SW2 SW4
CN20/21 CN16/15
PCI-E to PCI bridge
LSI53C1020 SCSI
controller
USB pin header (5-pin)
SATA port (7-pin)
Internal SCSI connector
Serial port
Serial 10 pin header
(Tx,Rx only)
No Population
rJ5
U26
CN2
CNY1
CN9
CN12 External SCSI
connector
CN15/16 USB ports
CN20/21 GbE ports
CNY1 DVI-I Connector
rJ3/5 CompactPCI
Connectors
SW1/2/3/4 Swiches
No Population
9
