Summary of Contents for ADLINK Technology cPCI-6510 Series

  • Page 1 Artisan Technology Group is your source for q new and certified-used/pre-owned equipme • FAST SHIPPING AND SERVICE CENTER REPAIRS WE BUY USED EQUIPM DELIVERY Experienced engineers and technicians on staff Sell your excess, un at our full-service, in-house repair center We also offer credit •...
  • Page 2 Series Low Power 6U CompactPCI Processor Blade ® with Intel Core™ i7 and two PMC sites User’s Manual 2.02 Manual Rev. November 13, 2014 Revision Date: 50-15071-1020 Part No: Advance Technologies; Automate the World.
  • Page 3 Revision History Revision Release Date Description of Change(s) 2.00 2010/09/24 Initial Release Updated RTM list, Mode Switch (SW2) definition, 2.01 2010/11/24 IPMI User Guide; added NT Mode EEPROM programming instructions 2.02 2014/11/13 Add PMC slot -12V support note...

  • Page 4: Preface

    Preface Copyright 2010-14 ADLINK Technology Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 5 Using this Manual Audience and Scope The cPCI-6510 User’s Manual is intended for hardware technicians and systems operators with knowledge of installing, configuring and operating industrial grade CompactPCI modules. Manual Organization This manual is organized as follows: Chapter 1, Overview: Introduces the cPCI-6510, its features, block diagrams, and package contents.
  • Page 6 cPCI-6510 Conventions Take note of the following conventions used throughout this manual to make sure that users perform certain tasks and instructions properly. Additional information, aids, and tips that help users perform tasks. NOTE: NOTE: Information to prevent minor physical injury, component dam- age, data loss, and/or program corruption when trying to com- plete a task.
  • Page 7 This page intentionally left blank. Preface...

  • Page 8: Table Of Contents

    Chipset................18 Super I/O ................19 Battery ................19 PMC/XMC Sites..............19 BIOS Recovery ..............20 4 Board Interfaces ............... 21 cPCI-6510 Series Board Layout - Top Side....... 21 cPCI-6510 Series Board Layout - Bottom Side ....22 Table of Contents...
  • Page 9 cPCI-6510 SBC Front Panel ..........23 Connector Pin Assignments..........24 Switch and Jumper Settings ..........38 5 Getting Started ..............41 Hard Drive Installation............42 CompactFlash Card Installation......... 45 PMC/XMC Module Installation ........... 46 Installing the cPCI-6510 to the Chassis ......47 Installing the RTM to the Chassis ........
  • Page 10 cPCI-6510 Communications with IPMC..........92 IPMI Sensors List............... 92 Relevant Documents ............92 Important Safety Instructions ..........93 Getting Service..............95 Table of Contents...
  • Page 11 This page intentionally left blank. Table of Contents...

  • Page 12: List Of Tables

    cPCI-6510 List of Tables Table 2-1: cPCI-6510 Specifications ......... 8 Table 2-2: cPCI-6510 I/O Connectivity ........10 Table 2-3: CompactPCI Input Voltage Characteristics .... 11 Table 2-4: Idle Mode Power Consumption ......12 Table 2-5: 100% CPU Usage Power Consumption ....12 Table 4-1: cPCI-6510 Front Panel Status LED Descriptions ...
  • Page 13 This page intentionally left blank. List of Tables...

  • Page 14: List Of Figures

    Figure 2-2: Core i7-620LE Power Dissipation Graph (TDP 25W) 14 Figure 2-3: Core i7-620UE Power Dissipation Graph (TDP 18W) 15 Figure 4-1: cPCI-6510 Series Board Layout - Top Side .... 21 Figure 4-2: cPCI-6510 Series Board Layout - Bottom Side ..22 Figure 4-3: cPCI-6510 Series Front Panel Layout .....
  • Page 15 This page intentionally left blank. List of Figures...

  • Page 16: Overview

    DVI and one VGA when accompanied by the appropriate Rear Transition Module. For flexibility of use, the cPCI-6510 Series can be installed in a standard CompactPCI system slot as system master, or peripheral slot as a PCI device. Through hardware switch setting, the cPCI-6510 optionally supports operation in system or peripheral slots as a standalone blade.

  • Page 17: Features

    1.2 Features 6U CompactPCI SBC in 4HP width form factor µFC-BGA package Intel® Core™ i7 processor, up to 2.53GHz Mobile Intel® BD82QM57 PCH (Platform Controller Hub) Dual Channel DDR3 ECC SDRAM at 800 or 1066MHz sol- dered onboard, up to 8GB 64-bit/66MHz CompactPCI Interface based on PCI specifica- tions, 3.3V and 5V signaling Supports operation in system slot as system master or in...

  • Page 18: Block Diagram

    COM4 6x USB 82574L 3x SATA PCI-X 64b/133M PCI 64b/66M GbE3 TMDSB PMC 2 2.5” HDD GbE4 5x GPIO KB/MS Rear I/O 2x COM PCIe x4 Rear I/O LVDS IPMB 0/1 J1/J2 J3/J4/J5 Figure 1-1: cPCI-6510 Series Block Diagram Overview...

  • Page 19: Product List

    1.4 Product List Products included in the cPCI-6510 Series include: Processor Blade cPCI-6510: 4HP width (single-slot) 6U CompactPCI blade featuring single Intel® Core™i7 processor, dual channel DDR3-800/1066 soldered onboard SDRAM with ECC, 2x PMC or 1x PMC and 1x XMC, 2x USB, 2x GbE and CF...

  • Page 20: Package Contents

    Processor Blade The cPCI-6510 Series Processor Blade CPU, RAM will differ depending on options selected Thermal module is assembled on the board RJ-45 to DB-9 cable for RJ-45 COM port (cPCI-6510V only) 2.5”...
  • Page 21 This page intentionally left blank. Overview...

  • Page 22: Specifications

    cPCI-6510 Specifications 2.1 cPCI-6510 Specifications PICMG® 2.0 CompactPCI® Rev. 3.0 PICMG® 2.1 Hot Swap Specification Rev.2.0 CompactPCI PICMG® 2.9 System Management Bus Rev. 1.0 Standard PICMG® 2.16 Packet Switching Backplane Rev.1.0 Standard 6U CompactPCI® Board size: 233.23 mm x 160mm Mechanical Single slot (4HP, 20.32mm) width CompactPCI®...

  • Page 23: Table 2-1: Cpci-6510 Specifications

    One 16C550 compatible RJ-45 RS-232 port on front panel (cPCI-6510V only) Serial Ports Two serial ports routed to rear I/O 2.5” SATA HDD direct connector onboard (cPCI-6510V only) Storage CompactFlash Type II socket onboard Interfaces AMI® EFI BIOS 64Mbit SPI flash memory BIOS Supports PICMG®...
  • Page 24 cPCI-6510 Notes: 1. 7.4 "Programming NT Mode EEPROM Map" on page 59 for instructions on how to set the PCIe-to-PCI bridge on the cPCI-6510 to Non-Transparent mode to allow operation in a peripheral slot. 2. ADLINK-certified thermal design. The thermal performance is dependent on the chassis cooling design.

  • Page 25: I/O Connectivity

    2.2 I/O Connectivity cPCI-6510 Processor Blade cPCI-6510 cPCI-6510V Function Faceplate Board Faceplate Board — — — — USB 2.0 — — 1 (RJ-45) — — — DVI-I — — — — — — — 1 (2.5” HDD) Serial ATA — —...

  • Page 26: Power Requirements

    cPCI-6510 2.3 Power Requirements In order to guarantee a stable functionality of the system, it is rec- ommended to provide more power than the system requires. An industrial power supply unit should be able to provide at least twice as much power as the entire system requires of each voltage.

  • Page 27: Table 2-4: Idle Mode Power Consumption

    Power Consumption This section provides information on the power consumption of the cPCI-6510 Series with different CPUs, 2GB DDR3-800/1066 sol- dered memory, and 100GB SATA HDD. The system was tested in Idle Mode and Full Load Mode under Windows XP running Burn-in Test 6.0.

  • Page 28: Thermal Requirements

    2.4 Thermal Requirements This section provides information on the thermal requirements of the cPCI-6510 Series. Cooling of the board and its components is provided by the thermal module (passive heatsink) and is depen- dent on sufficient airflow from the chassis.

  • Page 29: Figure 2-1: Core I7-610E Power Dissipation Graph (Tdp 35W)

    Intel® Core™ i7-610E Airflow Rate (CFM) 100% TDP 75% TDP Figure 2-1: Core i7-610E Power Dissipation Graph (TDP 35W) Intel® Core™ i7-620LE 90.0 80.0 70.0 60.0 50.0 40.0 30.0 20.0 10.0 Airflow Rate (CFM) 100% TDP 75% TDP Figure 2-2: Core i7-620LE Power Dissipation Graph (TDP 25W) Specifications...

  • Page 30: Figure 2-3: Core I7-620Ue Power Dissipation Graph (Tdp 18W)

    cPCI-6510 Intel® Core™ i7-620UE 100.0 90.0 80.0 70.0 60.0 50.0 40.0 30.0 20.0 10.0 Airflow Rate (CFM) 100% TDP 75% TDP Figure 2-3: Core i7-620UE Power Dissipation Graph (TDP 18W) Specifications...
  • Page 31 Thermal Management Features When the CPU temperature exceeds its maximum junction tem- perature (T ), the CPU’s thermal management features will j,Max reduce power consumption (and thus performance) in an attempt to reduce the core junction temperature. Use of the CPU’s thermal management features is intended for short periods of time when running power intensive applications.

  • Page 32: Functional Description

    Functional Description The following sections describe the cPCI-6510 Series features and functions. Processor Intel® Core™ i7 Processor The Intel® Core™ i7-620LE/UE and i7-610E are 64-bit, multi-core mobile processors built on a 32 nanometer process technology. The processors are designed for a two-chip platform consisting of...

  • Page 33: Chipset

    Using 2Gb device technologies, the largest memory capac- ity is 8GB 3.2 Chipset Mobile Intel® QM57 Express Chipset The cPCI-6510 Series incorporates the Mobile Intel® QM57 Express Chipset, also referred to as PCH (Platform Controller Hub), to provide extensive I/O support. Functions and capabilities include: PCI Express Base 2.0 Specification support for up to eight...

  • Page 34: Super I/O

    A Rayovac BR2032 is equipped on board by default. 3.5 PMC/XMC Sites The cPCI-6510 series supports two PMC sites for front panel I/O expansion. The PMC sites provides a maximum 64bit/133MHz PCI-X bus link using a Pericom PI7C9X130 PCIe-to-PCI bridge and PCIe x4 link.

  • Page 35: Bios Recovery

    3.6 BIOS Recovery The cPCI-6510 Series features AMI® EFI BIOS with BIOS recov- ery. If the BIOS becomes corrupted and you are unable to boot your system, follow the instructions in Section 7.3 “BIOS Recov- ery” on page 57. Functional Description...

  • Page 36: Board Interfaces

    BOM options to offer different features. cPCI-6510 cPCI-6510V SDRAM SDRAM DB-6920SAT connector QM57 PCH CompactFlash socket Soldered SDRAM XMC connector SDRAM CompactPCI connectors PMC connectors J1-5 JN1-8 Switches SW1-3 Figure 4-1: cPCI-6510 Series Board Layout - Top Side Board Interfaces...

  • Page 37: Cpci-6510 Series Board Layout - Bottom Side

    4.2 cPCI-6510 Series Board Layout - Bottom Side SDRAM Switches Soldered SDRAM SW4/5/6/8 SDRAM Figure 4-2: cPCI-6510 Series Board Layout - Bottom Side Board Interfaces...

  • Page 38: Cpci-6510 Sbc Front Panel

    4.3 cPCI-6510 SBC Front Panel cPCI-6510V COM1 DVI-I PMC/XMC 2x USB GbE 1/2 cPCI-6510 Status LEDs Figure 4-3: cPCI-6510 Series Front Panel Layout Status LEDs Color Condition Indication System is off Power (P) Green System is on Handles closed, System is on...

  • Page 39: Connector Pin Assignments

    4.4 Connector Pin Assignments Refer to “cPCI-6510 Series Board Layout - Top Side” on page 21 and “cPCI-6510 Series Front Panel Layout” on page 23 for con- nector locations USB Connectors Pin # Signal Name UV0- UV0+ Table 4-2: USB Connector Pin Definition...

  • Page 40: Table 4-4: Gbe Connector Pin Definitions

    cPCI-6510 RJ-45 Gigabit Ethernet Connectors 10BASE-T/100BAS Pin # 1000BASE-T E-TX BI_DA+ BI_DA- BI_DB+ BI_DC+ BI_DC- Speed Activity BI_DB- BI_DD+ BI_DD- Table 4-4: GbE Connector Pin Definitions Speed LED Activity LED Status (CN4, CN5) (Green/Amber) (Amber) Network link is not established or system powered off Link 10 Mbps...

  • Page 41: Table 4-5: Dvi-I Connector Pin Definition

    DVI-I Connector Pin # Signal Pin # Signal TMDS Data2- Hot Plug Detect TMDS Data2+ TMDS Data0- TMDSData0+ DDC Clock [SCL] DDC Data [SDA] Analog vertical sync TMDS Clock + TMDS Data1- TMDS Clock - TMDS Data1+ Analog Red Analog Green Analog Blue Analog Horizontal Sync +5 V Power...

  • Page 42: Table 4-6: Db-6920Sat Sata Connector Pin Definition

    cPCI-6510 Serial ATA Connector on DB-6920SAT Pin # Signal Signal Power Reserved P13~P15 Table 4-6: DB-6920SAT SATA Connector Pin Definition Board Interfaces...

  • Page 43: Table 4-7: Pmc Connector Pin Definitions

    PMC Connector (JN1/5, JN2/6, JN3/7, JN4/8) Pin# JN1/5 Signal JN2/6 Signal JN3/7 Signal JN4/8 Signal PMC_TCK P12V PIO1 N12V* PMC_TRST-L PIO2 PMC_TMS PIO3 PCIX_INTA-L NC (PMC_TDO) PCIX_CBE-L7 PIO4 PCIX_INTB-L PMC_TDI PCIX_CBE-L6 PIO5 PCIX_INTC-L PCIX_CBE-L5 PIO6 PMC_MOD-L1 PCIX_CBE-L4 PIO7 PIO8 PCIX_INTD-L PMC_VIO PIO9 PCIX_PAR64...
  • Page 44 cPCI-6510 Pin# JN1/5 Signal JN2/6 Signal JN3/7 Signal JN4/8 Signal PCIX_FRAME-L PIO33 PCIX_AD48 PIO34 PCIX_TRDY-L PCIX_AD47 PIO35 PCIX_IRDY-L P3V3 PCIX_AD46 PIO36 PCIX_DEVSEL-L PCIX_AD45 PIO37 PCIX_STOP-L PIO38 PCIX_PCIXCAP PCIX_PERR-L PIO39 PCIX_LOCK-L PCIX_AD44 PIO40 P3V3 PCIX_AD43 PIO41 PCIX_SERR-L PCIX_AD42 PIO42 PCIX_PAR PCIX_CBE-L1 PCIX_AD41 PIO43 PIO44...

  • Page 45: Table 4-8: Xmc Connector Pin Definition

    XMC Connector (CN8) Pin# PETp0 PETn0 3.3V PETp1 PETn1 VPWR TRST# MRSTI# PETp2 PETn2 3.3V PETp3 PETn3 VPWR MRSTO# PETp4 PETn4 3.3V PETp5 PETn5 VPWR +12V PETp6 PETn6 3.3V PETp7 PETn7 VPWR -12V VPWR PERp0 PERn0 MBIST# PERp1 PERn1 VPWR MPRESENT# PERp2 PERn2...

  • Page 46: Table 4-9: Compactflash Connector Pin Definition

    cPCI-6510 CompactFlash Connector Signal Name Pin# Pin# Signal Name DD11 DD12 DD13 DD14 DD15 CS1# CS3# SDIOR# SDIOW# IRQ15 PCSEL BRSTDRV# SDIORDY DMARQ DMACK# IDEACT# 66DECT IOIS16# DD10 Table 4-9: CompactFlash Connector Pin Definition Board Interfaces...

  • Page 47: Table 4-10: Db-6920Sat Connector Pin Definition

    DB-6920SAT Connector (CN3) Signal Name Pin # Pin # Signal Name P3V3 P3V3 P3V3 P3V3 P1V8 P1V8 P1V8 SATA-TXN0 SATA-TXP0 SATA-RXN0 SATA-RXP0 RESET# Table 4-10: DB-6920SAT Connector Pin Definition Board Interfaces...

  • Page 48: Table 4-11: Compactpci J1 Connector Pin Definition

    cPCI-6510 CompactPCI J1 Connector Pin Assignment -12V TRST# +12V TCK# TMS# TDI# IRQA# IRQB# IRQC# IRQD# +5V_IPMB HEALTHY# V(I/O) RESET# GNT0# REQ0# +3.3V CLK0 AD31 AD30 AD29 AD28 AD27 AD26 V(I/O) AD25 AD24 CBE3# IDSEL AD23 AD22 AD21 +3.3V AD20 AD19 AD18 AD17...

  • Page 49: Table 4-12: Compactpci J2 Connector Pin Definition

    CompactPCI J2 Connector Pin Assignment CLK1 REQ1# GNT1# REQ2# CLK2 CLK3 SYSEN# GNT2# REQ3# CLK4 GNT3# REQ4# GNT4# V(I/O) CBE7# CBE6# CBE5# V(I/O) CBE4# PAR64 AD63 AD62 AD61 AD60 AD59 V(I/O) AD58 AD57 AD56 AD55 AD54 AD53 AD52 V(I/O) AD51 AD50 AD49 AD48...

  • Page 50: Table 4-13: Compactpci J3 Connector Pin Definition

    cPCI-6510 CompactPCI J3 Pin Assignment Pin Z 1 GND HDA_RST# HDA_SYNC HDA_BIT_CLK HDA_SDOUT HDA_SDIN0 2 GND HDA_SDIN1 HDA_SDIN2 HDA_DOCK_EN# HAD_DOCK_RST# GND 3 GND KBDATA KBCLK MSDATA MSCLK 4 GND SATA-TX4+ SATA-TX4- SATA-TX3+ SATA-TX3- 5 GND 6 GND SATA-RX4+ SATA-RX4- SATA-RX3+ SATA-RX3- 7 GND COM4-TX...

  • Page 51: Table 4-14: Compactpci J4 Connector Pin Definition

    CompactPCI J4 Connector Pin Assignment PMC1 IO:64 PMC1 IO:63 PMC1 IO:62 PMC1 IO:61 GND GND PMC1 IO:60 PMC1 IO:59 PMC1 IO:58 PMC1 IO:57 PMC1 IO:56 GND GND PMC1 IO:55 PMC1 IO:54 PMC1 IO:53 PMC1 IO:52 PMC1 IO:51 GND GND PMC1 IO:50 PMC1 IO:49 PMC1 IO:48 PMC1 IO:47 PMC1 IO:46 GND...

  • Page 52: Table 4-15: Compactpci J5 Connector Pin Definition

    cPCI-6510 CompactPCI J5 Pin Assignment PCIE-TX0+ PCIE-TX0- PCIE-RX0+ PCIE-RX0- PCIE-TX1+ PCIE-TX1- PCIE-RX1+ PCIE-RX1- PCIE-TX2+ PCIE-TX2- PCIE-RX2+ PCIE-RX2- PCIE-TX3+ PCIE-TX3- PCIE-RX3+ PCIE-RX3- PCIE-CLK+ PCIE-CLK- RESET# GND LVDS_DATA3- LVDS_DATA3+ LVDS_CLK LVDS_DATA GPIO1 GPIO2 GPIO3 GPIO4 GPIO5 TDC0+ TDC0- TDC1+ TDC1- TDC2+ TDC2- TLC+ TLC- DVI_DATA...

  • Page 53: Switch And Jumper Settings

    4.5 Switch and Jumper Settings Refer to “cPCI-6510 Series Board Layout - Top Side” on page 21 and “cPCI-6510 Series Board Layout - Bottom Side” on page 22 for switch locations. SW1 & SW4 (Debug use only) The switches SW1 & 4 are for debugging purposes and should be left in the default settings.

  • Page 54: Table 4-16: Mode Switch Settings

    cPCI-6510 Pin# Status Description The cPCI-6510 cannot boot-up when installed in a peripheral slot if there is no host board in the system slot. The cPCI-6510 is able to boot-up when installed in a peripheral slot if there is no host board in the system slot. The cPCI-6510 behaves as a system board in all slots.

  • Page 55: Table 4-18: Com1/Debug Switch Settings

    COM1/Debug Switch (SW5) Switch SW5 sets the RJ-45 COM1 serial port as a standard RS-232 serial port or as an IPMI debugging port. Mode RS-232 COM port (default) IPMI debugging port Table 4-18: COM1/Debug Switch Settings Clear CMOS Switch (SW6) Press switch SW6 to clear the CMOS and reset the CMOS val- ues to default.

  • Page 56: Getting Started

    cPCI-6510 Getting Started This chapter describes the installation of the following components to the cPCI-6510 and rear transition modules: 2.5” SATA hard drive CompactFlash card PMC/XMC module installation cPCI-6510 installation to chassis RTM installation to chassis Getting Started...

  • Page 57: Hard Drive Installation

    5.1 Hard Drive Installation The cPCI-6510V provides space to install a slim type 2.5” Serial-ATA hard drive. Installing a SATA Hard Drive - cPCI-6510V Install a CF card to the cPCI-6510 before installing the hard drive (see “Installing a CF card – cPCI-6510” on page 45). NOTE: NOTE: 1.
  • Page 58 cPCI-6510 2. Secure the HDD to the bracket with four screws provided. 3. Position the hard drive assembly on the cPCI-6510V so that the standoffs are aligned with the screw holes on the board, and the connector on the DB-6920SAT adapter board is aligned with the board-to-board connector (CN3).
  • Page 59 4. Press the DB-6920SAT adapter onto the board-to-board connector until it is properly seated. Secure the adapter to the board with the two screws provided. Support the hard drive assembly when turning the board over to proceed with step 5. CAUTION: 5.

  • Page 60: Compactflash Card Installation

    Installing a CF card – cPCI-6510 Insert the CF card into the CF slot on the cPCI-6510 (CN5 - see “cPCI-6510 Series Board Layout - Top Side” on page 21). Then install the card retaining bracket with the 2 screws provided to pre- vent the CF card from sliding out of the slot.

  • Page 61: Pmc/Xmc Module Installation

    5.3 PMC/XMC Module Installation The cPCI-6510 provides one PMC and one PMC/XMC slot and the cPCI-6510V provides one PMC/XMC slot. The PMC/XMC slots support 3.3V V(I/O) and 5V VPWR only. For optional 5V V(I/O) and 12V VPWR support, please contact ADLINK. Installing a PMC/XMC Module 1.

  • Page 62: Installing The Cpci-6510 To The Chassis

    cPCI-6510 5.4 Installing the cPCI-6510 to the Chassis The cPCI-6510 may be installed in a system or peripheral slot of a 6U CompactPCI chassis. These instructions are for reference only. Refer to the user guide that comes with the chassis for more information.

  • Page 63: Installing The Rtm To The Chassis

    RTMs. Refer to previous sections for peripheral connectivity of all I/O ports on the RTM. When installing the cPCI-6510 Series and related RTMs, make sure the RTM is the correct matching model. You must install the correct RTM to enable functions (I/O inter- faces) on the rear panel.

  • Page 64: Driver Installation

    cPCI-6510 Driver Installation The cPCI-6510 drivers can be found on the ADLINK All-In-One CD at X:\cPCI\cPCI-6510\ or from the ADLINK website (http://www.adlinktech.com). ADLINK provides validated driv- ers for chipset, graphics and LAN on Windows XP Professional, Windows Vista, and Windows 7. 6.1 Driver Installation Procedure The following describes the driver installation procedures for Win- dows XP.
  • Page 65 This page intentionally left blank. Driver Installation...

  • Page 66: Utilities

    cPCI-6510 Utilities 7.1 Watchdog Timer This section describes the operation of the cPCI-6510’s watchdog timer (WDT). The primary function of the WDT is to monitor the cPCI-6510's operation and to reset the system if a software appli- cation fails to function as programmed. The following WDT func- tions may be controlled using a software application: enabling and disabling reloading timeout value...
  • Page 67 For a detailed programming sample, refer to the sample code pro- vided on the ADLINK All-In-One CD. You can find it in the following directory: X:\cPCI\cPCI-6510\WDT. Sample Code The sample program written in C shown below offers an interactive way to test the Watchdog Timer under DOS. #include<stdio.h>...
  • Page 68 cPCI-6510 //Exit index port void Exit_IT8783_Config(unsigned int flag) if(flag) IT8783_ioPort = 0x4e; outportb(IT8783_ioPort, 0x02); outportb(IT8783_ioPort+1, 0x02); //Check chip void Get_IT8783_ID(unsigned int &ID1, unsigned int &ID2) outportb(IT8783_ioPort, 0x20); ID1 = inportb(IT8783_ioPort+1); outportb(IT8783_ioPort, 0x21); ID2 = inportb(IT8783_ioPort+1); //WDT and LED program void IT8783_3_WDTRun(unsigned int count_value, unsigned int PLEDflag) //for cPCI-6510 unsigned long tempCount;...
  • Page 69 registerValue &= 0xfe; // set GP60 is alternate function outportb(IT8783_ioPort+1, registerValue); outportb(IT8783_ioPort, 0xCD); registerValue = inportb(IT8783_ioPort + 1); registerValue |= 0x01; // set GP60 is output outportb(IT8783_ioPort+1, registerValue); outportb(IT8783_ioPort, 0xf8); outportb(IT8783_ioPort+1, 0x30);// PLED mapping to GP60 outportb(IT8783_ioPort, 0xf9); registerValue = inportb(IT8783_ioPort + 1); registerValue |= 0x02;...
  • Page 70 cPCI-6510 tempCount = count_value / 60; if((count_value%60) > 30) tempCount++; if(tempCount > 65535) tempCount = 65535; printf("WDT timeout in %d minutes.\n", tempCount); else outportb(IT8783_ioPort, 0x72); registerValue = inportb(IT8783_ioPort+1); registerValue |= 0x80; tempCount = count_value; if(tempCount != 0) printf("WDT timeout in %d seconds.\n", tempCount);...

  • Page 71: Preboot Execution Environment (Pxe)

    7.2 Preboot Execution Environment (PXE) The cPCI-6510 series supports the Intel® Preboot Execution Envi- ronment (PXE) that is capable of booting up or executing an OS installation through an Ethernet port. To use PXE, there must be a DHCP server on the network with one or more servers running PXE and MTFTP services.

  • Page 72: Bios Recovery

    7.3 BIOS Recovery The cPCI-6510 Series features AMI® EFI BIOS with BIOS recov- ery. If the BIOS becomes corrupted and you are unable to boot your system, the system will sound 4 beeps. Follow the instruc- tions below to re-flash the BIOS and recover the system.
  • Page 73 6. During the BIOS recovery process, you will see the following: 7. After the flash update is completed, power down the system and restart. The system should now boot up normally. Utilities...

  • Page 74: Programming Nt Mode Eeprom Map

    cPCI-6510 7.4 Programming NT Mode EEPROM Map The cPCI-6510 supports operation in peripheral slot as PCI device with PCI bus communication with the system board (Universal Mode). To operate in a peripheral slot in Non-Transparent mode, the PCIe-to-PCI bridge on the cPCI-6510 should be set to Non-Transparent mode by programming the NT mode EEPROM map.
  • Page 75 This page intentionally left blank. Utilities...

  • Page 76: Bios Setup Utility

    cPCI-6510 BIOS Setup Utility The following chapter describes basic navigation for the AMIBIOS®8 BIOS setup utility. 8.1 Starting the BIOS To enter the setup screen, follow these steps: 1. Power on the motherboard 2. Press the < Delete > key on your keyboard when you see the following text prompt: <...
  • Page 77 Setup Menu The main BIOS setup menu is the first screen that you can navi- gate. Each main BIOS setup menu option is described in this user’s guide. The Main BIOS setup menu screen has two main frames. The left frame displays all the options that can be configured.
  • Page 78 cPCI-6510 Navigation There is a hot key legend located in the right frame on most Note: setup screens. Keyboard Commands Selects the highlighted option or submenu. Enter The Left and Right “Arrow” keys allow you to select a setup < > screen.

  • Page 79: Main Setup

    8.2 Main Setup When you first enter the Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by select- ing the Main tab. There are two Main Setup options. They are described in this section.

  • Page 80: Advanced Bios Setup

    cPCI-6510 8.3 Advanced BIOS Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as SuperIO Configuration, to go to the sub menu for that item.
  • Page 81 PCI Subsystem Settings PCI Latency Timer Value to be programmed into PCI Latency Timer Register. Options: 32 PCI Bus Clocks, 64 PCI Bus Clocks, 96 PCI Bus Clocks, 128 PCI Bus Clocks, 160 PCI Bus Clocks, 192 PCI Bus Clocks, 224 PCI Bus Clocks, 248 PCI Bus Clocks. ASPM Support Set the ASPM (Active State Power Management) level.
  • Page 82 cPCI-6510 CPU Configuration Hyper-Threading Enables/disables Hyper-Threading Technology. Active Processor Cores Number of cores to enable in each processor package. Options: All, 1, 2. Intel Virtualization Enables/disables Intel Virtualization Technology. Power Technology Power management feature. Options: Disabled, Energy Efficient, Custom. TDC Limit Turbo-XE Mode Processor TDC Limit in 1/8 A granularity.
  • Page 83 SATA Configuration SATA Mode The SATA can be configured as a legacy IDE, RAID and AHCI mode. Serial ATA Controller 0 This item specifies whether SATA Controller 0 is initialized in Compatible or Enhanced mode of operation. The settings are Disabled, Compatible and Enhanced.
  • Page 84 cPCI-6510 Intel IGD SWSCI OpRegion Configuration DVMT/FIXED Memory Select DVMT/FIXED Mode Memory size used by internal Graphics Device. Options: 128MB, 256MB, Maximum. IGD – Boot Type Selects the Video Device(s) to be activated during POST. This option has no effect if external graphics present. Options: CRT, DVI, TV, CRT+DVI.
  • Page 85 USB Configuration Legacy USB Support Legacy USB Support refers to USB mouse and keyboard sup- port. Normally if this option is not enabled, any attached USB mouse or keyboard will not become available until a USB com- patible operating system is fully booted with all USB drivers loaded.
  • Page 86 cPCI-6510 Super IO Configuration Serial Port 1/2/4 Configuration Sub-menu allows you to Enable/Disable and set the parame- ters of Serial Ports 1, 2, 4. BIOS Setup Utility...
  • Page 87 PC Health Configuration BIOS Setup Utility...
  • Page 88 cPCI-6510 Console Redirection The settings specify how the host computer and the remote computer will exchange data. Both computers should have the same or compatible settings. The user can enable one serial port for Console Redirection. Only one port can be used for Console Redirection at any time. BIOS Setup Utility...
  • Page 89 Terminal Type VT-UTF8 is the preferred terminal type for out-of-band man- agement. The next best choice is VT100+ and then VT100. Options: VT100, VT100+, VT-UTF8, ASNI. Bits per Second Select the bit rate (bits/second) you want the serial port to use for console redirection.

  • Page 90: Chipset Configuration

    cPCI-6510 8.4 Chipset Configuration Select the Chipset tab from the setup screen to enter the Chipset BIOS Setup screen. You can select any of Chipset BIOS Setup options by highlighting it using the < Arrow > keys. The Chipset BIOS Setup screen is shown below. Memory Information and Display Configuration BIOS Setup Utility...
  • Page 91 Initial Graphic Adapter Allows you to select which graphics controller to use as the pri- mary boot device. Configuration options: IGD, PCI/IGD, PCI/PEG, PEG/IGD, PEG/PCI. IGD Memory IGD shared memory size. Options: Disabled, 32M, 64M, 128M. PCH Configuration SMBus Controller The SMBus controller.
  • Page 92 cPCI-6510 USB Configuration All USB Devices All USB Devices. Set this value to Enabled/Disabled. EHCI Controller 1 USB 2.0 (EHCI) support. Set this value to Enabled/Disabled. USB Port USB Port 0~7.Set this value to Enabled/Disabled. BIOS Setup Utility...

  • Page 93: Boot Configuration

    8.5 Boot Configuration Select the Boot tab from the setup screen to enter the Boot Con- figuration screen. You can select any of the items in the left frame of the screen to go to the sub menu for that item. You can display a Boot Configuration option by highlighting it using the <...
  • Page 94 cPCI-6510 Bootup Num-Lock This option sets the Num Lock status when the system is powered on. Setting it to On will turn on the Num Lock key when the system is booted up. Setting it to Off will not enable the Num Lock key on bootup.

  • Page 95: Security Setup

    8.6 Security Setup Administrator Password Use this option to set a password for administrators with full con- trol of the BIOS setup utility. User Password Use this option to set a password for users with limited access to the BIOS setup utility. BIOS Setup Utility...

  • Page 96: Save & Exit

    cPCI-6510 8.7 Save & Exit Select the Save & Exit tab from the setup screen to enter the Save & Exit setup screen. You can display a Save & Exit BIOS setup option by highlighting it using the < Arrow > keys. The Save & Exit BIOS setup screen is shown below.
  • Page 97 This page intentionally left blank. BIOS Setup Utility...

  • Page 98: Ipmi User Guide

    cPCI-6510 IPMI User Guide 9.1 Introduction This chapter is written for those who already have a basic under- standing of the newest implementation of the baseboard manage- ment controller (BMC) of the Intelligent Platform Management Interface (IPMI) specification rev. 2.0. It also describes the OEM extension IPMI command usages which are not listed in the IPMI specification.
  • Page 99 IPMI Command NetFn CMD Description Spec This is a broadcast version of the ‘Get Broadcast “Get Device ID’ command that is provided for 20.9 Device ID” the ‘discovery’ of Intelligent Devices on the IPMB IPMI Messaging Support Commands The Send Message command is used for bridging IPMI messages between Send Message 22.7...
  • Page 100 cPCI-6510 IPMI Command NetFn CMD Description Spec Sensor Device Commands This command returns general Get Device SDR 35.2 information about the collection of Info sensors in a Dynamic Sensor Device. The ‘Get Device SDR’ command allows SDR information for sensors for a Sensor Get Device SDR 35.3 Device (typically implemented...
  • Page 101 IPMI Command NetFn CMD Description Spec This command returns the present reading for sensor. The sensor device Get Sensor may return a stored version of a 35.14 Reading periodically updated reading, or the sensor device may scan to obtain the reading after receiving the request.

  • Page 102: Oem Commands Summary Table

    cPCI-6510 9.3 OEM Commands Summary Table Command NetFn Code Cmd Code OemShowRevision OEM (C0h) OemRescanGaInput OEM (C0h) OemTestFunction OEM (C0h) OemSetBlueLEDLongBlinking OEM (C0h) OemReportGeoAddress OEM (C0h) OemEnableSmbus OEM (C0h) OemDisableSmbus OEM (C0h) OemDispDebugVariable OEM (C0h) OemResetHost OEM (C0h) OemPowerOff OEM (C0h) OemPowerOn OEM (C0h) OemShowRevision...
  • Page 103 OemRescanGaInput This command is used to rescan the geo-address input pins and reset the IPMB address according to the input value. Action Byte Value Description NetFn/LUN for OEM Request OEM defined command Complete Code 00h means OK Response New IPMB address New IPMB address value OemTestFunction Internal test purposes only.
  • Page 104 cPCI-6510 OemReportGeoAddress This command can report the IPMB address, the GA pin input sta- tus, and the event forwarding control value. Action Byte Value Description NetFn/LUN for OEM Request OEM defined command Complete Code 00h means OK IPMB address IPMB address value Response GA value GA pin input status...
  • Page 105 OemDispDebugVariable This command can report up to 5 interval values for debug pur- poses. For developers only. Action Byte Value Description NetFn/LUN for OEM Request OEM defined command Complete Code 00h means OK *Debug variable 1 *Debug variable 2 Response *Debug variable 3 *Debug variable 4 *Debug variable 5...

  • Page 106: Compactpci Address Map

    cPCI-6510 OemPowerOn This command is implemented to control the system’s status if power-on is required. Operators can control the system remotely. Action Byte Value Description NetFn/LUN for OEM Request OEM defined command Response Complete Code 00h means OK 9.4 CompactPCI Address Map Since more than one system may be installed in a single chassis, we allocate each IPMB address based on GA input as peripheral cards.

  • Page 107: Communications With Ipmc

    9.5 Communications with IPMC Operating systems need to use a serial port to communicate with the IPMC. The resource setting of the serial port must be IO: 0x3E8 and IRQ: 3. The communication setting of the serial port must be BaudRate: 9600, DataBit: 8, ParityCheck: None, StopBit: 1, and FlowControl: None.
