Full-Size PICMG 1.3 Intel® Core™ i7/i5/i3
Manual Rev.:
Revision Date:
Part No:
Advance Technologies; Automate the World.
NuPRO-E340
LGA1155 SHB
User's Manual
2.02
April 23, 2012
50-13069-1020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NuPRO-E340 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADLINK Technology NuPRO-E340

Summary of Contents for ADLINK Technology NuPRO-E340

  • Page 1 NuPRO-E340 Full-Size PICMG 1.3 Intel® Core™ i7/i5/i3 LGA1155 SHB User’s Manual Manual Rev.: 2.02 Revision Date: April 23, 2012 Part No: 50-13069-1020 Advance Technologies; Automate the World.
  • Page 2 Revision History Revision Release Date Description of Change(s) 2.00 2011/09/01 Initial release Correct ATX 12V Power Connector label; add 2.01 2011/10/21 PS/2 KB/MS pin header definition Correct COM3, COM6 connector locations; add PCIe Ports 0-3 Configuration to BIOS (version 2.02 2012/04/23 A1.6 and higher);...

  • Page 3: Preface

    NuPRO-E340 Preface Copyright 2011-2012 ADLINK Technology, Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 Chapter 2, Hardware Information: Provides technical informa- tion on connectors and jumpers for configuring the NuPRO-E340. Chapter 3, Getting Started: Illustrates how to install components on the NuPRO-E340 such as CPU, heatsink, and memory mod- ules. Chapter 4, Driver Installation: Provides information on how to install the NuPRO-E340 device drivers.
  • Page 5 NuPRO-E340 Conventions Take note of the following conventions used throughout this manual to make sure that users perform certain tasks and instructions properly. Additional information, aids, and tips that help users perform tasks. NOTE: NOTE: Information to prevent minor physical injury, component dam- age, data loss, and/or program corruption when trying to com- plete a task.
  • Page 6 This page intentionally left blank. Preface...

  • Page 7: Table Of Contents

    NuPRO-E340 Table of Contents Revision History..............ii Preface ..................iii List of Figures ................ xi List of Tables................ xiii 1 Introduction ................ 1 Overview................1 Features................2 Specifications............... 3 Block Diagram ..............5 Functional Description ............6 Mechanical Drawing ............9 I/O Connectivity ..............
  • Page 8 Intel® Q67 Express Chipset Driver ........32 Display Driver..............32 Ethernet Driver..............33 Intel® Rapid Storage Technology Utility ......33 Intel® Active Management Technology ......33 TPM Driver................. 33 USB 3.0 Driver ..............34 Audio Driver ............... 34 5 BIOS Setup ................ 35 Starting the BIOS ...............
  • Page 9 NuPRO-E340 Sample Code ..............71 B Appendix: System Resources.......... 75 System Memory Map............75 Direct Memory Access Channels........75 IO Map ................76 Interrupt Request (IRQ) Lines..........77 Important Safety Instructions ..........83 Getting Service..............85...
  • Page 10 This page intentionally left blank.

  • Page 11: List Of Figures

    NuPRO-E340 List of Figures Figure 1-1: NuPRO-E340 Block Diagram .......... 5 Figure 1-2: NuPRO-E340 Board Dimensions ........9 Figure 2-1: Rear Panel I/O Ports............13 Figure 2-2: Connectors and Jumpers..........15 List of Figures...
  • Page 12 This page intentionally left blank. List of Figures...

  • Page 13: List Of Tables

    NuPRO-E340 List of Tables Table 1-1: NuPRO-E340 General Specifications......3 Table 1-2: NuPRO-E340 I/O Connectivity ........10 Table 1-3: Core™ i7-2600 Processor Power Consumption.... 11 Table B-1: System Memory Map............. 75 Table B-2: Direct Memory Access Channels........75 Table B-3: IO Map ................76 Table B-4: IRQ Lines PIC Mode............
  • Page 14 This page intentionally left blank. List of Tables...

  • Page 15: Introduction

    8 GB in two DIMM slots. These advanced features, coupled with PCI Express® x16 expan- sion capability, dual PCI Express®-based Gigabit Ethernet, SATA 6 Gb/s and USB 3.0 support make the NuPRO-E340 ideal for vision and automation control applications. Introduction...

  • Page 16: Features

    1.2 Features Supports Intel® Core™ i7/i5/i3 and Pentium® processors in LGA1155 package Integrated Intel® HD Graphics PCI Express® x16 expansion capability via backplane Dual Gigabit Ethernet 2x USB 3.0 ports onboard 12x USB 2.0 ports (8x onboard, 4x on backplane) 2x SATA 6 Gb/s ports onboard 4x SATA 3 Gb/s ports (2x onboard, 2x on backplane) 6x COM ports (including 1x RS-232/422/485/485+)

  • Page 17: Specifications

    • 1x DVI-D via onboard pin-header (opt. cable bracket • 1x parallel port • PCIe-x16, PCIe-x4 and PCI 32bit/33MHz via golden PCIe/PCI fingers Graphics Integrated • Integrated Intel® HD Graphics External • PCI Express x16 Table 1-1: NuPRO-E340 General Specifications Introduction...
  • Page 18 Dimensions • 338 x 126 mm (L x W) Operating Temp. • 0ºC to 60ºC Storage Temp. • -20ºC to 80ºC Relative • 10% to 90% non-condensing Humidity Safety • CE, FCC Class A Table 1-1: NuPRO-E340 General Specifications Introduction...

  • Page 19: Block Diagram

    (2x rear panel) PCI 32-bit/33MHz USB 2.0 PCI Bus USB 2.0 on backplane Controller (8x onboard, 4x internal) Codec Header for DB-Audio2 KB/Mouse SPI BIOS ITE8783 RS-232 LPC Super I/O Hardware (COM2-6) Monitor RS-232/422/ 485/485+ (COM1) Figure 1-1: NuPRO-E340 Block Diagram Introduction...

  • Page 20: Functional Description

    1.5 Functional Description Processor Support The NuPRO-E340 is PICMG 1.3 System Host Board supporting the 2nd generation Intel® Core™ processor family (Intel® Core™ i7/i5/i3) in LGA1155 socket. An integrated memory controller sup- ports dual channel 1066/1333 MHz DDR3 and Intel® HD Graphics is integrated onboard the CPU.
  • Page 21 NuPRO-E340 Serial ATA The NuPRO-E340 provides six Serial ATA ports with data transfer rates of up to 6.0 GB/s on 2 ports and up to 3.0 GB/s on 4 ports. Intel® Rapid Storage Technology supports AHCI and RAID 0/1/5/10 functionality.
  • Page 22 certificates. Systems supporting TPM offer improved hard- ware-based security in numerous applications, such as file and folder encryption, local password management, S-MIME e-mail, VPN and PKI authentication and wireless authentication for 802.1x and LEAP. Intel® Active Management Technology Intel® Active Management Technology (Intel® AMT) is hard- ware-based technology for remotely managing and securing PCs out-of-band.

  • Page 23: Mechanical Drawing

    NuPRO-E340 1.6 Mechanical Drawing Dimensions in mm Figure 1-2: NuPRO-E340 Board Dimensions Introduction...

  • Page 24: I/O Connectivity

    — 2.54” pitch COM1-2 — — 2.00" pitch COM3-6 — — Parallel port — — — SATA — — PCIe x4 — — — PCIe x16 — — — PCI 32bit/33MHz — — — Table 1-2: NuPRO-E340 I/O Connectivity Introduction...

  • Page 25: Power Consumption

    NuPRO-E340 1.8 Power Consumption Intel® Core™ i7-2600 Processor (8M Cache, 3.40 GHz) Test Configuration Intel® Core™ i7-2600 Processor 3.40 GHz (4 cores) Unigen 2GB DDR3 1333 UDIMM 240-pin Memory 2x 2GB in 2 DIMM slots Graphics Integrated Intel® HD Graphics SATA Channel 1 Seagate ST9160412AS Barracuda 7200.4 160GB...

  • Page 26: Package Contents

    2-port COM cable with bracket x2 for COM3-6 (2.0 mm pitch) Driver DVD User’s manual The NuPRO-E340 must be protected from static discharge and physical shock. Never remove any of the socketed parts except at a static-free workstation. Use the anti-static bag shipped with WARNING: the product to handle the board.

  • Page 27: Hardware Information

    NuPRO-E340 Hardware Information This chapter provides information on the NuPRO-E340 board lay- out, connector pin assignments, and jumper settings. 2.1 Rear Panel I/O Ports Figure 2-1: Rear Panel I/O Ports Connector Description LAN1 port (RJ-45) Gigabit Ethernet (supports Intel® AMT)
  • Page 28 LAN (RJ-45) Ports 10BASE-T/ Pin # 1000BASE-T 100BASE-TX BI_DA+ BI_DA- LED1 LED2 BI_DB+ BI_DC+ BI_DC- BI_DB- BI_DD+ BI_DD- Refer to the table below for the LAN port LED definitions. LED1 LED2 Status Description Status Description No Link 10 Mb connection Linked Green 100 Mb connection...

  • Page 29: Board Layout

    NuPRO-E340 2.2 Board Layout 8 9 10 11 12 Figure 2-2: Connectors and Jumpers Connector Description CN24 ATX 12V Power connector DIMM1/2 DDR3 DIMM slots CN23 System Panel pin header FAN2 System fan connector CN2/4 SATA 6 Gb/s connectors (blue)

  • Page 30: Onboard Connectors

    2.3 Onboard Connectors Serial ATA Connectors (CN2/4/5/7) Pin # Signal USB 2.0 Connectors (CN3/6/8/X1) Pin # Signal Pin # Signal USB0- USB1- USB0+ USB1+ PS/2 Keyboard/Mouse Pin Header (CN27) Pin # Signal Pin # Signal KBDATA KBCLK MSDATA MSCLK KM_VCC ATX 12V Power Connector (CN24) Pin # Signal...
  • Page 31 NuPRO-E340 HD Audio Daughter Board Connector (CN9) This connector is designed for use with the ADLINK DB-Audio2 daughter board. Pin # Signal Function Ground AUD_BCLK Audio Clock Ground ICH_AUD_SDIN1 Audio Data Input + 5V ICH_AUD_SDOUT Audio Data Output P5V_AUD + 5V P3V3_DVDD 3.3V...
  • Page 32 COM1 Connector (RS-422/485/485+) (CN10) Pin # RS-422/485+ RS-485 TXD- Data- TXD+ Data+ RXD+ RXD- Note: See “COM1 Mode Jumper Settings (JP1-4)” on page 22. COM1 COM2 COM3 COM4 COM5 COM6 Connector CN10 CN11 CN12 CN13 CN14 CN16 Pitch 2.54 mm 2.54 mm 2.00 mm 2.00 mm 2.00 mm 2.00 mm Hardware Information...
  • Page 33 NuPRO-E340 Parallel Port Connector (CN15) Pin # Signal Pin # Signal Line Printer Strobe Auto-Feed Parallel Data 0 Error Parallel Data 1 Initialize Parallel Data 2 Select Parallel Data 3 Ground Parallel Data 4 Ground Parallel Data 5 Ground Parallel Data 6...
  • Page 34 System Panel Connector (CN23) Connects to chassis-mounted buttons, speakers, and LEDs. Pin # Signal Function Pin Group WDSPK Speaker signal Chassis Speaker Power Ground Key Lock KEYLOCK Keyboard lock PLED Power LED signal Power LED Power LED pull-up Ground Reset Button RESETBT RESET signal Ground...
  • Page 35 NuPRO-E340 DVI-D Onboard Connector(CN17) Pin # Signal Pin # Signal DVI-Clock+ DVI-Data0- DVI-Clock- DVI-Data0+ DVI-I2C-Clock DVI-Data1- DVI-I2C-Data DVI-Data1+ DVI-HPD DVI-Data2- DVI-Data2+ DVI-D Bracket Connector (optional cable w/ bracket, P/N 30-01052-2000) Pin # Signal Pin # Signal TMDS Data2- TMDS Data3+...

  • Page 36: Jumpers

    2.4 Jumpers Clear CMOS (JBAT1) The CMOS RAM data contains the date / time and BIOS setting information. CMOS is powered by the onboard button cell battery. To erase the CMOS RAM data: 1. Power down and disconnect power from the system. 2.

  • Page 37: Getting Started

    This chapter provides information on how to install components on the NuPRO-E340 SHB. 3.1 Installing the CPU The NuPRO-E340 supports an Intel® Core™ i7/i5/i3 or Pentium® processor in an LGA1155 socket. Disconnect all power to the board before installing a CPU to prevent damaging the board and CPU.
  • Page 38 2. Raise the locking arm to unlock the load plate. 3. Lift the load plate to uncover the socket. 4. Remove the plastic protective cover from the socket. Note the locations of the alignment keys (A) and Pin 1 indicator (B). Do NOT touch socket contacts.
  • Page 39 NuPRO-E340 5. Hold the CPU using thumb and forefinger as shown. Position the CPU over the socket, matching the notches on the sides of the CPU with the alignment keys on the socket (A). The golden triangle on the CPU must be positioned at the corner of the socket with the Pin 1 indi- cator as shown (B).
  • Page 40 7. Gently lower the load plate. Make sure the front edge of the plate is under the screw as indicated. 8. Lower the locking arm and fasten it to the retention tab (A). The load plate should be locked underneath the screw as shown (B).

  • Page 41: Installing The Cpu Fan And Heatsink

    NuPRO-E340 3.2 Installing the CPU Fan and Heatsink The CPU requires a chassis with an airflow inlet and maximum internal ambient temperature of 50° C. A especially-designed CPU fan and heatsink must be installed before using the SHB. CAUTION: Failure to install a CPU fan and heatsink may damage the sys- tem host board and/or the CPU.

  • Page 42: Installing Memory Modules

    3.3 Installing Memory Modules The NuPRO-E340 supports up to 8 GB of DDR3 1066/1333 MHz memory modules in two DIMM sockets. A DDR3 module has a 240-pin footprint compared to the legacy 184-pin DDR DIMM. DDR3 modules are notched to facilitate correct installation in the DIMM sockets.
  • Page 43 NuPRO-E340 3. Align the memory module on the socket making sure that the notch matches the break on the socket. Notch Break 4. Insert the module firmly into the slot until the retaining clips snap back inwards and the module is securely seated.
  • Page 44 This page intentionally left blank. Getting Started...

  • Page 45: Driver Installation

    NuPRO-E340 Driver Installation This chapter provides information on how to install the NuPRO-E340 device drivers under Windows XP. The device drivers are located in the following ADLINK All-in-One DVD directories: Chipset \NuPRO\NuPRO-E340\Chipset\ Display \NuPRO\NuPRO-E340\VGA\ Ethernet \NuPRO\NuPRO-E340\Ethernet\ \NuPRO\NuPRO-E340\TPM\ .Net Framework \NuPRO\NuPRO-E340\VGA\...

  • Page 46: Intel® Q67 Express Chipset Driver

    Integrated Intel® HD Graphics This section describes the driver installation for the Integrated Intel® HD Graphics. Follow these instructions to install the display driver: 1. Locate the directory X:\NuPRO\NuPRO-E340\VGA\ on the ADLINK All-in-One DVD, and extract the contents of the following archive: Microsoft_Net_Framework_v3.5_SP1.zip 2.

  • Page 47: Ethernet Driver

    4.5 Intel® Rapid Storage Technology Utility Follow these instructions to install the Intel® Rapid Storage Technology utility. 1. Locate the directory X:\NuPRO\NuPRO-E340\Others\ on the ADLINK All-in-One DVD, and extract the file setup.exe from the following archive: Intel_Rapid_Storage_Technology_All_WinOS_v9.5.0.1037. zip. 2. Run the program setup.exe and follow the onscreen instructions.

  • Page 48: Usb 3.0 Driver

    4.8 USB 3.0 Driver Follow these instructions to install the TPM driver. 1. Locate the directory X:\NuPRO\NuPRO-E340\Others\ on the ADLINK All-in-One DVD, and extract the file setup.exe from the following archive: USB3.0.zip. 2. Run the program setup.exe and follow the onscreen instructions.

  • Page 49: Bios Setup

    NuPRO-E340 BIOS Setup The following chapter describes basic navigation for the AMIBIOS® EFI BIOS setup utility. 5.1 Starting the BIOS To enter the setup screen, follow these steps: 1. Power on the motherboard 2. Press the < Delete > key on your keyboard when you see the following text prompt: <...
  • Page 50 Setup Menu The main BIOS setup menu is the first screen that you can navi- gate. Each main BIOS setup menu option is described in this user’s guide. The Main BIOS setup menu screen has two main frames. The left frame displays all the options that can be configured.
  • Page 51 NuPRO-E340 Note: There is a hot key legend located in the right frame on most setup screens. The < F8 > key on your keyboard is the Fail-Safe key. It is not dis- played on the key legend by default. To set the Fail-Safe settings of the BIOS, press the <...
  • Page 52 The < F10 > key allows you to save any changes you have made and exit Setup. Press the < F10 > key to save your changes. The following screen will appear: Press the < Enter > key to save the configuration and exit. You can also use the <...

  • Page 53: Main Setup

    NuPRO-E340 5.2 Main Setup When you first enter the Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by select- ing the Main tab. There are two Main Setup options. They are described in this section.
  • Page 54 System Time/System Date Use this option to change the system time and date. Highlight Sys- tem Time or System Date using the < Arrow > keys. Enter new val- ues using the keyboard. Press the < Tab > key or the < Arrow > keys to move between fields.

  • Page 55: Advanced Bios Setup

    NuPRO-E340 5.3 Advanced BIOS Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as SuperIO Configuration, to go to the sub menu for that item.

  • Page 56: Acpi Settings

    5.3.1 ACPI Settings Enable APIC Auto Configuration BIOS ACPI Auto Configuration. Options: Enabled/Disabled. Enable Hibernation Enable or disable the system's ability to hibernate (S4 sleep state). This option may be not effective with some OS's. ACPI Sleep State Select the highest ACPI sleep state the system will enter, when the SUSPEND button is pressed.

  • Page 57: Trusted Computing

    NuPRO-E340 5.3.2 Trusted Computing Trusted computing is an industry standard to make personal com- puters more secure through a dedicated hardware chip, called a Trusted Platform Module (TPM). TPM Support This option enables or disables the TPM support. System reset is required.

  • Page 58: Cpu Configuration

    5.3.3 CPU Configuration Active Processor Cores Number of cores to enable in processor. Options: All, 1, 2. Limit CPUID Value Maximum When Enabled, the processor will limit the maximum CPUID input value to 03h when queried, even if the processor sup- ports a higher CPUID input value.
  • Page 59 NuPRO-E340 Intel® Virtualization Tech When enabled, Intel® Virtualization Technology (Intel® VT) makes a single system appear as multiple independent sys- tems to software. This allows for multiple, independent operat- ing systems to be running simultaneously on a single system. Power Technology Sets the power management features.

  • Page 60: Sata Configuration

    5.3.4 SATA Configuration SATA Mode Options: IDE, RAID, AHCI. Serial ATA Controller 0/1 Appears when SATA mode is set to IDE. This item specifies whether Serial ATA Controller 0/1 is initialized in Compatible or Enhanced mode of operation. The settings are Disabled, Com- patible and Enhanced.

  • Page 61: Intel Txt Configuration

    NuPRO-E340 5.3.5 Intel TXT Configuration Intel Trusted Execution Technology (Intel TXT) support can only be enabled when TPM is enabled, if the CPU supports Safer Mode Extensions (SMX), and Intel® Virtualization Technology (Intel® VT) and Intel® Virtualization Technology for Directed I/O (VT-d) are enabled.

  • Page 62: Intel Igd Swsci Opregion

    5.3.6 Intel IGD SWSCI OpRegion DVMT Mode This item allows the user to enable or disable the DVMT func- tion. DVMT/Fixed Memory Select DVMT/Fixed memory size used by the Integrated Graphics Device. Options: 128MB, 256MB, Maximum. IGD - Boot Type Select the video device which will be activated during POST.

  • Page 63: Usb Configuration

    NuPRO-E340 5.3.7 USB Configuration Legacy USB Support Legacy USB Support refers to USB mouse and keyboard sup- port. Normally if this option is not enabled, any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB driv- ers loaded.
  • Page 64 XHCI Hand-Off This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. Options: Enable, Disable. EHCI Hand-Off This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver.

  • Page 65: Super Io Configuration

    NuPRO-E340 5.3.8 Super IO Configuration Serial Port1-6 Configuration Enter the submenu for each serial port to enable/disable and view the I/O port and IRQ settings. Parallel Port Configuration Enter the submenu to enable/disable the parallel port and specify the base I/O port address.

  • Page 66: Hardware Monitor

    5.3.9 Hardware Monitor You can use this screen to view System Status information and to select options for FAN1 settings (FAN2 is set to Full On by default). Smart Fan 1 Mode Setting Three operating modes are provided for FAN1: Full Mode, Auto- matic Mode, and Manual Mode.
  • Page 67 NuPRO-E340 Fan Start PWM Sets the PWM value of the fan between Fan Off Temperature Limit and Fan Start Temperature Limit. Minimum value is 0 and maximum is 127. PWMSlope Setting The Slope PWM Value sets the rate of increase the fan speed when the temperature is above Fan Start Temperature Limit.

  • Page 68: 10Amt Configuration

    5.3.10 AMT Configuration This item allows the user to Enable/Disable the Intel AMT func- tion. Unconfigure AMT/ME This item allows the user to unprovision the AMT/ME function without a password. WatchDog Timer Options: Enabled/Disabled. OS WatchDog Timer Sets the OS WatchDog Timer (seconds). BIOS WatchDog Timer Sets the BIOS WatchDog Timer (seconds).

  • Page 69: 11Serial Port Console Redirection

    NuPRO-E340 5.3.11 Serial Port Console Redirection COM0/1 Console Redirection Options: Enabled/Disabled. Console Redirection Settings The settings specify how the host computer and the remote computer exchange data. Both computers should have the same or compatible settings. BIOS Setup...
  • Page 70 Terminal Type This option is used to select either VT100/VT-UTF8 or ANSI terminal type. Options: VT100, VT100+, VT-UTF8, ANSI. Bits per second Select the bits per second you want the serial port to use for console redirection. The options are 115200, 57600, 38400, 19200, 9600.
  • Page 71 NuPRO-E340 Serial Port for Out-of-Band Management These settings control the ACPI serial port redirection table (SPCR) which is used by Windows servers to provide Windows Emergency Management Services (EMS) and is independent from console redirection output. OoB Management or EMS...
  • Page 72 Flow Control Set this option to select Flow Control for console redirection. The settings for this value are None, Hardware RTS/CTS. Data Bits Displays the frame width for Out-of-Band Management. Parity Displays the parity for Out-of-Band Management. Stop Bits Displays the number of stop bits for Out-of-Band Management. BIOS Setup...

  • Page 73: Chipset Setup

    NuPRO-E340 5.4 Chipset Setup Select the Chipset tab from the setup screen to enter the Chipset BIOS Setup screen. You can select any of the items in the left frame of the screen to go to the sub menu for that item. The Chip- set BIOS Setup screen is shown below.

  • Page 74: Graphics And Memory Bridge Configuration

    5.4.1 Graphics and Memory Bridge Configuration VT-d Intel Virtualization Technology for Directed I/O. Options: Enabled/ Disabled. Initial Graphics Adapter Allows you to select which graphics controller to use as the pri- mary boot device. Options: IGD, PCI/IGD, PCI/PEG, PEG/IGD, PEG/PCI. IGD Memory IGD shared memory size, Options: Disable/32M/64M/128M.

  • Page 75: Pch Bridge Configuration

    NuPRO-E340 5.4.2 PCH Bridge Configuration 82574L LAN Controller Controls the onboard Intel 82574L LAN controller. Options: Enabled/Disabled. Restore on AC Power Loss Determines which state the computer enters when AC power is restored after a power loss. The options for this value are Last State, Power On and Power Off.
  • Page 76 PCI Express Port Configuration PCI Express Port 1~8 Configures the PCI Express ports in of the chipset. Options: Auto, Enable, Disable. PCIe Sub Decode Enable or disable the PCIe Sub Decode port. This option is avail- able when the Subtractive Decode Agent is enable (PCHTrap9[14]) = '1b'.

  • Page 77: Management Engine Subsystem

    NuPRO-E340 5.4.3 Management Engine Subsystem ME Subsystem Options: Enabled/Disabled. ME Temporary Disable Options: Enabled/Disabled (reset required). End of POST Message Options: Enabled/Disabled. Execute MEBx Options: Enabled/Disabled. MEBx Mode Options: Normal, Hidden Ctrl+P, Enter MEBx setup. BIOS Setup...
  • Page 78 Integrated Clock Chip Configuration ICC Enable Integrated Clock Chip. Options: Enabled/Disabled. BIOS Setup...

  • Page 79: Boot Configuration

    NuPRO-E340 5.5 Boot Configuration Select the Boot tab from the setup screen to enter the Boot BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Boot Device Priority, to go to the sub menu for that item.
  • Page 80 When it is disabled, the BIOS will display the normal POST messages, instead of the full-screen logo. Gate A20 Active Options: Upon Request, Always. Boot Option Priorities Set the boot device options to determine the sequence in which the computer checks which device to boot from. Hard Drive BBS Priorities The Boot devices are listed in groups by device type.

  • Page 81: Security Setup

    NuPRO-E340 5.6 Security Setup Password Support Two Levels of Password Protection Provides both a Supervisor and a User password. If you use both passwords, the Supervisor password must be set first. The system can be configured so that all users must enter a...
  • Page 82 Remember the Password Keep a record of the new password when the password is changed. If you forget the password, you must erase the sys- tem configuration information in NVRAM. To access the sub menu for the following items, select the item and press <...

  • Page 83: Exit Menu

    NuPRO-E340 5.7 Exit Menu Select the Exit tab from the setup screen to enter the Exit BIOS Setup screen. You can display an Exit BIOS Setup option by high- lighting it using the < Arrow > keys. The Exit BIOS Setup screen is shown below.
  • Page 84 Discard Changes and Exit Select this option to quit Setup without making any permanent changes to the system configuration. Discard Changes and Exit Setup Now? [Ok] [Cancel] appears in the window. Select Ok to discard changes and exit. Save Changes and Reset Reset the system after saving the changes.

  • Page 85: A Appendix: Watchdog Timer

    NuPRO-E340 Appendix A - Watchdog Timer A sample program for configuring the NuPRO-E340’s watchdog timer is included on the ADLINK All-in-One DVD in the following directory: \NuPRO\NuPRO-E340\WDT. A.1 Sample Code #include<stdio.h> #include<dos.h> static unsigned int IT8783_ioPort = 0x2e; void Enter_IT8783_Config(unsigned int flag) if(flag) IT8783_ioPort = 0x4e;...
  • Page 86 Get_IT8783_ID(unsigned int &ID1, unsigned int &ID2) outportb(IT8783_ioPort, 0x20); ID1 = inportb(IT8783_ioPort+1); outportb(IT8783_ioPort, 0x21); ID2 = inportb(IT8783_ioPort+1); void IT8783_WDTRun(unsigned int count_value, unsigned int PLEDflag) //for NuPRO-E340 unsigned long tempCount; unsigned int registerValue; outportb(IT8783_ioPort, 0x07); outportb(IT8783_ioPort+1, 0x07);// Device 7 outportb(IT8783_ioPort, 0xf8); outportb(IT8783_ioPort+1, 0x00);// PLED mapping to...
  • Page 87 NuPRO-E340 outportb(IT8783_ioPort, 0xf8); outportb(IT8783_ioPort+1, 0x1f);// PLED mapping to GP37 outportb(IT8783_ioPort, 0xf9); registerValue = inportb(IT8783_ioPort + 1); registerValue |= 0x02; registerValue &= 0xfb; outportb(IT8783_ioPort+1, registerValue); outportb(IT8783_ioPort, 0x71); registerValue = inportb(IT8783_ioPort + 1); registerValue &= 0xfe; outportb(IT8783_ioPort+1, registerValue); outportb(IT8783_ioPort, 0x72); registerValue = inportb(IT8783_ioPort + 1);...
  • Page 88 registerValue = inportb(IT8783_ioPort+1); registerValue |= 0x80; tempCount = count_value; if(tempCount != 0) printf("WDT timeout in %d seconds.\n", tempCount); registerValue |= 0x40; //Enable WDT output through KBRST else printf("WDT is Disabled.\n"); registerValue &= 0xbf; //Disable WDT output through KBRST outportb(IT8783_ioPort+1, registerValue); // set WDT count is second outportb(IT8783_ioPort, 0x71);...

  • Page 89: B Appendix: System Resources

    NuPRO-E340 Appendix B - System Resources B.1 System Memory Map Address Range Address Range Size Description (decimal) (hex) FFE00000 – (4GB-2MB) 2 MB High BIOS Area FFFFFFFF (4GB-18MB) – FEE00000 – 1 MB FSB Interrupt Memory Space (4GB-17MB-1) FEEFFFFF (4GB-20MB) –...

  • Page 90: Io Map

    B.3 IO Map Hex Range Device 000-01F DMA controller 1, 8237A-5 equivalent 020-02D and 030-03F Interrupt controller 1, 8259 equivalent 02E-02F,04E-04F LPC SIO (ITE8783) configuration index/data registers 040-042, 050-052 Timer, 8254-2 equivalent 060, 062, 064, 066 8742 equivalent (keyboard) NMI control and status 070-077 Real Time Clock Controller (bit 7 -NMI mask) 080-091...

  • Page 91: Interrupt Request (Irq) Lines

    NuPRO-E340 B.4 Interrupt Request (IRQ) Lines IRQ Lines PIC Mode Typical Interrupt IRQ# Connected to Pin Available Resource Counter 0 Keyboard controller Cascade interrupt from slave PIC IRQ3 via SERIRQ, IRQ3 Serial Port 2 (COM2) Note (1) at ISA bus...
  • Page 92 IRQ Lines APIC Mode Typical Interrupt IRQ# Connected to Pin Available Resource System Timer Keyboard controller PCI / ISA Serial Port 2 (COM2) / IRQ3 via SERIRQ, Note (1) PCI / ISA IRQ3 at ISA bus Serial Port 1 (COM1) / IRQ4 via SERIRQ, Note (1) PCI / ISA...

  • Page 93: Table B-5: Irq Lines Apic Mode

    NuPRO-E340 Typical Interrupt IRQ# Connected to Pin Available Resource PCIE Port 0/1/2/3/4/5/6/7, P.E.G. Root Port, SATA Host controller, SMBus Controller, Thermal Controller, SOL (COM7) PCIE Port 0/1/2/3/4/5/6/7, P.E.G. Root Port, SATA Host controller, SATA Host controller#1, PCH internal GBE controller,...
  • Page 94 PCI Configuration Space Map Bus # Device # Function # Routing Description Intel Host Bridge Internal Intel IGD 0FFH P.E.G. Port Intel Integrated Graphics Internal Device Intel Management Engine Internal Interface #1 Intel Management Engine Internal Interface #2 Internal IDE-R controller Internal PCI Serial controller Internal...

  • Page 95: Table B-6: Pci Configuration Space Map

    NuPRO-E340 Bus # Device # Function # Routing Description 0FFh Internal PCIE Port #3 0FFh Internal Intel 82574L LAN Controller 0FFh Internal PCIE Port #5 0FFh Internal USB 3.0 Controller 0FFh Internal PCIE Port #7 Internal PCI Slot 0 Internal...

  • Page 96: Table B-7: Pci Interrupt Routing Map

    PCI Interrupt Routing Map PIRQ INT Line INTA INTB INTC INTD P.E.G. Root Port INTA INTB INTC INTD SATA Controller SATA Controller 1 SMBus controller Thermal Controller EHCI 1 EHCI 2 Intel GBE HECI host 1 HECI host 2 IDER Controller KT Controller PCIE port 0 INTA INTB INTC INTD...

  • Page 97: Important Safety Instructions

    NuPRO-E340 Important Safety Instructions For user safety, please read and follow all instructions, WARNINGS, CAUTIONS, and NOTES marked in this manual and on the associated equipment before handling/operating the equipment. Read these safety instructions carefully. Keep this user’s manual for future reference.
  • Page 98 Never attempt to fix the equipment. Equipment should only be serviced by qualified personnel. A Lithium-type battery may be provided for uninterrupted, backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type. Dispose of used batteries appropriately. WARNING: Equipment must be serviced by authorized technicians when:...

  • Page 99: Getting Service

    5215 Hellyer Avenue, #110, San Jose, CA 95138, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-360-0222 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. Address: (201203) 300 Fang Chun Rd., Zhangjiang Hi-Tech Park, Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax:...
  • Page 100 84 Genting Lane #07-02A, Cityneon Design Centre, Singapore 349584 Tel: +65-6844-2261 Fax: +65-6844-2263 Email: singapore@adlinktech.com ADLINK Technology Singapore Pte. Ltd. (Indian Liaison Office) Address: 1st Floor, #50-56 (Between 16th/17th Cross) Margosa Plaza, Margosa Main Road, Malleswaram, Bangalore-560055, India Tel: +91-80-65605817, +91-80-42246107 Fax: +91-80-23464606 Email: india@adlinktech.com...
