Terminal Legend Function/Description
XFMR Low voltage transformer connections.
Aux. power output terminals. These terminals supply 12VDC or 24VDC not affected by trig-
+ AUX –
ger, reset or fire alarm interface.
Switched power output. Fail-Safe [LOCK +] supplies positive power when unit is not trig-
LOCK +
gered and FACP interface is inactive. Fail-Secure [STRIKE +] supplies positive power when
STRIKE +
unit is triggered and/or fire alarm interface is activated.
COM –
[COM –] supplies negative power.
Supervised by 2.2K end of line resistor FACP interface. Short or open will cause power to
FACP1
be dropped to terminal marked [LOCK +] and supply power to terminal marked [STRIKE +].
FACP2
Condition can be maintained even after restoration of the circuit (latching mode).
TRG INPUT Short between these two terminals will cause power to be dropped to the terminal marked
NO, GND [LOCK+] and supplied to the terminal marked [STRIKE +].
RESET Momentary short between these terminals would end latching FACP interface condition.
NO, GND Feature active only if latching FACP is selected (SW1 ON).
+ BAT – Stand-by battery connections.
Red
ON
OFF
Slow Blink
Rapid Blink
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 4 -

Terminal Identification:

LED Diagnostics:

Power Supply Status
Normal function.
No DC output.
Loss of AC.
Unit is triggered, awaiting reset. Fire alarm interface activated.
CAUTION: To reduce the risk of electric shock do not open
enclosure. There are no user serviceable parts inside. Refer servicing
to qualified service personnel.
AL125220 Series
