AL125220 Series
Access Control
Power Supply/Chargers
Models Include:
AL125220
- Includes power supply, transformer, cam lock, and enclosure.
- 8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm).
- Accommodates one (1) 12VDC/4AH battery.
AL125X220
- Includes power supply, transformer, cam lock, and enclosure.
- 13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.6mm).
- Accommodates up to two (2) 12VDC/7AH batteries.
Installation Guide
Rev. 102706
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix AL125220 Series
Summary of Contents for Altronix AL125220 Series
- Page 1 AL125220 Series Access Control Power Supply/Chargers Models Include: AL125220 - Includes power supply, transformer, cam lock, and enclosure. - 8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm). - Accommodates one (1) 12VDC/4AH battery. AL125X220 - Includes power supply, transformer, cam lock, and enclosure.
- Page 2 Overview: Altronix AL125220 and AL125X220 Power Supply/Chargers convert 220VAC (working range 198VAC - 256VAC), 50/60Hz input into two individually PTC protected auto-resettable 12VDC or 24VDC outputs (see specifications). They are intended for use in Access Control applications and applications requiring an interface with Fire Alarm Control Panels.
- Page 3 Note: Maximum charging current under discharge is 400mA. Note: Expected battery life is 5 years; however, it is recommended changing batteries in 4 years or less if needed. AL125220 Series - 3 -...
- Page 4 (servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. - 4 - AL125220 Series...
- Page 5 AL125220 Series - 5 -...
- Page 6 Notes: - 6 - AL125220 Series...
- Page 7 3.625” (92mm) 1.25” (31.8mm) 1.25” 0.6” (15.2mm) 0.6” (15.2mm) (31.75mm) 6.05” (153.7mm) 1.125” 1.125” (28.6mm) (28.6mm) 1” 1” (25.4mm) (25.4mm) 6.05” (153.7mm) 1.25” 0.6” (15.2mm) 0.6” (15.2mm) (31.75mm) 1” (25.4mm) 5.25” (133.35mm) 1” 1” (25.4mm) (25.4mm) AL125220 Series - 7 -...
- Page 8 (25.4mm) (25.4mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. IIAL125220series F29U MEMBER - 8 -...
