AL1024NK1
Dual Output Power Supply/Charger Kit
Fully assembled kit includes:
- (1) AL1024ULXB2 - Power Supply/Charger
- (1) VR6 - Voltage Regulator
Installation Guide
Rev. 1024NK1_022322
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AL1024NK1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Altronix AL1024NK1

  • Page 1 AL1024NK1 Dual Output Power Supply/Charger Kit Fully assembled kit includes: - (1) AL1024ULXB2 - Power Supply/Charger - (1) VR6 - Voltage Regulator Installation Guide More than just power. Rev. 1024NK1_022322 Installing Company: _______________ Service Rep. Name: __________________________________ Address: _____________________________________________ Phone #: __________________...
  • Page 2: Specifications

    Overview: Altronix AL1024NK1 dual output power supply/charger kit converts a 115VAC, 60Hz input into one (1) 5VDC or 12VDC selectable output at up to 6A supply current and one (1) 24VDC output. It also offers a suite of features that includes overvoltage protection, AC fail supervision, low battery supervision and battery presence supervision (form “C”...
  • Page 3: Installation Instructions

    8. To delay reporting for up to 6 hrs., cut “AC Delay” jumper and reset power to unit (Fig. 1f, pg. 4). 9. For Access Control Applications: mount UL Listed tamper switch (Altronix model TS112 or equivalent) at the top of the enclosure. Slide tamper switch bracket onto the edge or the enclosure approx. 2” from the right side (Fig.
  • Page 4: Led Diagnostics

    Terminal Legend Function/Description + IN – Power input from AL1024ULXB2, factory installed. + OUT – 5VDC @ 6A or 12VDC @ 6A, depending on SW1 setting. Fig. 1 - AL1024ULXB2 Board Configuration AC DELAY - 4 - AL1024NK1 Installation Guide...
  • Page 5: Battery Connection

    Fig. 2 - AL1024NK1 Configuration Enclosure Edge of Enclosure Tamper Switch (included) To Access Control Panel or UL Listed Reporting Device VAC power mains 115VAC power mains non power-limited power-limited Green Lead 115VAC power mains Fig. 2a non power-limited T FAIL Battery &...
  • Page 6 I*1.8 (safety factor) ________________ AH Note: AL1024NK1 power supply is designed to work with batteries up to 65AH. Please note: line [I] must not exceeds 36AH. You have to reduce either stand-by current consumption or stand-by time in order to comply with requirement.
  • Page 7 NEC Power-Limited Wiring Requirements for AL1024NK1: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits.
  • Page 8 1.0” (25.4mm) 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIAL1024NK1 B23V...
