AL1012X220 Series
Power Supply/Charger
Installation Guide
Models Include:
AL1012X220
- Single Output.
AL1012XPD4220
- Four (4) Fuse Protected Outputs.
AL1012XPD8220
- Eight (8) Fuse Protected Outputs.
AL1012XPD16220
- Sixteen (16) Fuse Protected Outputs.
Rev. 090302
AL1012XPD4CB220
- Four (4) PTC Protected Outputs.
AL1012XPD8CB220
- Eight (8) PTC Protected Outputs.
AL1012XPD16CB220
- Sixteen (16) PTC Protected Outputs.
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix AL1012X220 Series
Summary of Contents for Altronix AL1012X220 Series
- Page 1 AL1012X220 Series Power Supply/Charger Installation Guide Models Include: AL1012X220 - Single Output. AL1012XPD4220 AL1012XPD4CB220 - Four (4) Fuse Protected Outputs. - Four (4) PTC Protected Outputs. AL1012XPD8220 AL1012XPD8CB220 - Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs.
- Page 2 Overview: Altronix AL1012X220 is a power supply that converts a nominal 220VAC (working range 198VAC-256VAC) 50/60Hz input to a 12VDC output (see specifications). AL1012X220 is a base unit for a series of multi-output power supply/chargers including: AL1012XPD4220, AL1012XPD4CB220, AL1012XPD8220, AL1012XPD8CB220, AL1012XPD16220, AL1012XPD16CB220 (Refer to AL1012X220 Series Power Supply Configuration Reference Chart below).
- Page 3 Note: Maximum charging current under discharges is 0.7A. Note: Expected battery life is 5 years; however, it is recommended changing batteries in 4 years or less if needed. 12VDC Rechargeable Ba (optional) AL1012X220 Series - 3 -...
- Page 4 Battery and AC Supervision Circuit 220VAC Use separate knockout power mains Divider Wire Strap (from Enclosure to Door) Provide 0.25" Power Distribution Module separation between all other circuits INPUT DC Output to devices 12VDC Rechargeable Battery (optional) - 4 - AL1012X220 Series...
- Page 5 Stand-by battery connections. Maximum charge rate 0.7A. Power Distribution Module Terminal Legend Function/Description PD4/PD4CB PD8/PD8CB 1P to 4P 1P to 8P Positive DC power outputs. 1N to 4N 1N to 8N Negative DC power outputs. AL1012X220 Series - 5 -...
- Page 6 COMMON POWER OUTPUTS DC Output to devices DC Output to devices From Power Supply From Power Supply Board Board 1P-8P Power Outputs, 1P-8P Power Outputs, (Factory Installed) (Factory Installed) 1N-8N Common Outputs 1N-8N Common Outputs - 6 - AL1012X220 Series...
- Page 7 Notes: AL1012X220 Series - 7 -...
- Page 8 (117.22mm) (38.1mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIAL1012X220 Series D24R...
