AL168 Series
Multi-Output Power Supplies
Models Include:
AL168CB
- 16VAC @ 6A (100VA) or
18VAC @ 5.5A (100VA).
- Eight (8) PTC protected outputs.
AL168175CB
- 16VAC @ 10A (175VA).
- Eight (8) PTC protected outputs.
AL168300CB
- 16VAC @ 18A (350VA) or
18VAC @ 16A (350VA).
- Eight (8) PTC protected outputs.
Installation Guide
Rev. 070109
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
AL168300CBM
- 16VAC @ 18A (350VA) or
18VAC @ 16A (350VA).
- Eight (8) PTC protected outputs.
AL168600CB
- 16VAC @ 40A (700VA) or
18VAC @ 36A (700VA).
- Eight (8) PTC protected outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix AL168 Series
Summary of Contents for Altronix AL168 Series
- Page 1 AL168 Series Multi-Output Power Supplies Models Include: AL168CB AL168300CBM - 16VAC @ 6A (100VA) or - 16VAC @ 18A (350VA) or 18VAC @ 5.5A (100VA). 18VAC @ 16A (350VA). - Eight (8) PTC protected outputs. - Eight (8) PTC protected outputs.
-
Page 2: Specifications
Overview: Altronix AL168CB Series Multi-Output Power Supplies provide 16VAC/18VAC distributed via eight (8) auto- resettable PTC protected outputs for powering multiple security system or access control panels. Eight (8) Output AL168 Reference Chart: Total Number Output 115VAC Output of PTC... -
Page 3: Terminal Identification
CAUTION: Determine the maximum operating voltage of the equipment being powered before adjusting the output voltage. 6. Connect devices to terminals marked [1P] - [1N] through [4P] - [4N] on PD4CB board (Figs. 3, 5, pgs. 6, 8) or terminals marked [1P] - [1N] through [8P] - [8N] on PD8CB board (Figs. 1, 2, and 4, pgs. 4-5, 7), carefully observing polarity. - Page 4 Fig. 1 - AL168CB Input 115VAC, 50/60Hz, 0.9A Voltage Selection Configuration 16VAC Output (Yellow) (Black) 18VAC Output (Black) (Yellow) - 4 - AL168CB Series Installation Guide...
- Page 5 Fig. 2 - AL168175CB Illuminated Power Switch Input 115VAC, 50/60Hz, 1.45A AL168CB Series Installation Guide - 5 -...
- Page 6 Fig. 3 - AL168300CB Input 115VAC, 50/60Hz, 2.7A Voltage Selection Configuration 16VAC Output (Yellow) (Black) 18VAC Output (Black) (Yellow) - 6 - AL168CB Series Installation Guide...
- Page 7 Fig. 4 - AL168300CBM Illuminated Power Switch Input 115VAC, 50/60Hz, 2.7A Voltage Selection Configuration 16VAC Output (Yellow) (Black) 18VAC Output (Black) (Yellow) AL168CB Series Installation Guide - 7 -...
- Page 8 Fig. 5 - AL168600CB Illuminated Power Switch Input 115VAC, 50/60Hz, 5.4A Voltage Selection Configuration 16VAC Output (Yellow) (Black) 18VAC Output (Black) (Yellow) - 8 - AL168CB Series Installation Guide...
- Page 9 Notes: AL168CB Series Installation Guide - 9 -...
- Page 10 Enclosure Dimensions (H x W x D) for AL168CB and AL168175CB 8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm) 7.25” (184.2mm) 3.625” (92mm) 1.25” (31.8mm) 1.25” 0.6” (15.2mm) 0.6” (15.2mm) (31.75mm) 6.05” (153.7mm) 1.125” 1.125” (28.6mm) (28.6mm) 1” 1”...
- Page 11 Enclosure Dimensions (H x W x D) for AL168300CBM 8.5” x 7.5” x 3.875” (215.9mm x 191mm x 98.4mm) 3.63” (92.2mm) 1.25” (31.75mm) 3.85” (97.79mm) 7.25” (184.15mm) 0.6” 1.25” 1.25” (15.24mm) 0.6” (31.75mm) (31.75mm) (15.24mm) 1” 1” (25.4mm) (25.4mm) 0.9” 0.9”...
- Page 12 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IIAL168CB Series...
