Summary of Contents for Altronix AL175ULX2
- Page 1 AL175ULX2 Access Control Power Supply/Charger Altronix Corp. 140 58th St. Brooklyn, NY More than just power. Rev. 052019...
- Page 2 See Terminal Identification Chart on Pg. 3 for a description of each terminal function. 1. Mount AL175ULX2 in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding.
- Page 3 3. Set the AL175ULX2 to the desired DC output voltage by setting switch SW1 to the appropriate position (see Power Supply Output Specifications Table, Pg. 2). 4. Measure output voltage before connecting devices. This helps avoiding potential damage. 5. Connect battery to terminals marked [+ BAT –] (battery leads included). Use two (2) 12VDC batteries connected in series for 24VDC operation.
- Page 4 Fig. 1 - AL175ULX2 Input 115VAC 60Hz, 0.6A Green Lead AC Power (ground) Reset Switch White Black Lead Lead XFMR JUMPER SW1 ON - 24V TRG1 TRG2 OFF - 12V Molex Connector AL175ULB LOCK + STRIKE + COM -- AUX +...
- Page 5 Typical Application Diagrams: Fig. 2 Typical single mag lock or door strike installation with fire alarm tie-in using trigger controlled output: DOOR STRIKE LOCK + STRIKE + MAG LOCK COM -- PROX/CARD READER AUX + ACCESS CONTROL DEVICE AUX -- TRG2 TRG1 FACP...
- Page 6 AUX -- Fig. 5 Latching fire alarm tie-in with manual reset: ACCESS CONTROL DEVICE LOCK + STRIKE + MAG LOCK COM -- FACP TRG2 TRG1 NO RESET SWITCH Fig. 6 Multiple AL175ULX2 power supply connections: TRG1 TRG2 - 6 - AL175ULX...
- Page 7 Notes: AL175ULX - 7 -...
- Page 8 (117.22mm) (38.1mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIAL175ULX2 E20S - 8 -...
