PCI VELOCITY / OPTO ISO RS422/485
COM port values of 5 to 6, all preceding COM ports, must have
buffers assigned to them also.
Buffer Size.
/S512
Buffer size set to 512 bytes.
Hardware Handshaking.
/H,4
Type 4, 3 Wire Handshake selected for all ports. Type 4, 3
Wire Handshake selected for all ports.
Modifying Command Line Parameters.
When "assembled" the NEWCOM.SYS command line
looks like...
DEVICE=NEWCOM.SYS /A5-6,0140 /I 11,5-6 /B8 /S 512 /H,4
...and should be entered into the CONFIG.SYS file. Once you are
sure that these parameters have been entered correctly, restart your
PC and your PCI RS422/485 should be ready to use immediately.
Sample terminal applications are provided on "Serial Solutions
Disk 1 & 2" enabling communications to be established to your
peripherals quickly and easily.
Software Configuration
Chapter 3 Page 39
