Configuring Ports.

To view the settings of a port, select it and click on
settings, and then click on the resources tab:
Settings available in this window are:
Settings available in this window are:
1. Baud Rate - determines the baud rate at which the
selected port operates, the maximum value available is
921,600 (1 Megabaud.) Note: Many serial comms
applications will not actually register the ports as
running at baud rates of above 115200.
2. Data Bits.
3. Parity.
4. Stop Bits.
5. Flow Control.
Software Configuration
Change to suit remote device.
