- Page 1 Hardware Manual LPT & RS232 1.1 Edition September 1998...
- Page 2 Guarantee. FULL 36 MONTHS GUARANTEE. We guarantee your Serial Port Card for a full 36 months from purchase, parts and labour, provided it has been used in the specified manner. In the unlikely event of failure return your interface to your Dealer, with proof of purchase, who will determine whether to repair or replace this product with an equivalent unit.
- Page 3 PCI LPT & RS232 Introduction PCI LPT & RS232 MANUAL OUTLINE CONTENTS Chapter 1 - Optional Serial Solution Software. Chapter 2 - PCI LPT & RS232 Specifications. Chapter 3 - PCI LPT & RS232 Software Configuration Guide. The Layout Of This Manual Chapter 1 - Serial Solution Software , is an overview of the optional, ideal companion software package for our range of serial...
-
Page 4: Table Of Contents
PCI LPT & RS232 CHAPTER 1 ...4 SERIAL SOLUTIONS SOFTWARE... 4 Introduction..4 Introducing Serial Solution Software..4 Serial Solutions For DOS..5 Serial Solutions For Windows 3.x... 7 Serial Solutions For Windows 95... 7 Complete Documentation and Technical Backup..8 CHAPTER 2 ...9 PCI LPT &... - Page 5 PCI LPT & RS232 Restarting Windows... 27 Configuring Ports In DOS..28 Determining PCI LPT & RS232 Resources... 28 NEWCOM.SYS Parameters..29 Configuring And Installing NEWCOM.SYS... 30 Port Address..30 IRQ, Range... 31 Number Buffer..31 Buffer Size.
-
Page 6: Chapter 1
PCI LPT & RS232 SERIAL SOLUTIONS SOFTWARE. Introduction. This chapter is a brief advertisement for the OPTIONAL Serial Solutions SEPARATELY and is available from YOUR DEALER. Introducing Serial Solution Software. The perfect partner for any Serial Port is Serial Solutions Software! Serial Solutions is a fully featured suite of programs designed to squeeze the most from PC serial communications. -
Page 7: Serial Solutions For Dos
PCI LPT & RS232 Serial Solutions For DOS. Serial Solutions for DOS consists of the following programs: - NewCOM.sys A device driver, it supports COM1 to COM16, allowing 16 serial ports to be used under DOS. It also includes an interrupt handler for enhanced performance with user definable buffer languages, it is the heart of the Serial Solution. - Page 8 PCI LPT & RS232 Source code, make files and compiled ready to run programs supplied. TERM programs A suite of larger terminal emulation programs written in C (Cterm), Assembly language (Aterm), Pascal (Pasterm), BASIC (BASterm) and FORTRAN (FORterm) show how to access the NEWBIOS routines as well as the simple file I/O to ports.
-
Page 9: Serial Solutions For Windows 3.X
PCI LPT & RS232 Serial Solutions For Windows 3.x Serial Solutions for Windows 3.x works with Windows 3.0, 3.1 and 3.11 as well as Windows For Workgroups 3.11. Serial Solutions for Windows 3.x consists of the following programs: - Setup.exe The install routine for the package. -
Page 10: Complete Documentation And Technical Backup
PCI LPT & RS232 Serial Solutions Complete Documentation and Technical Backup. We believe in supplying complete documentation with every package we sell. The Serial Solution Software Package is no exception, it has an attractive manual in an A5 binder, containing over 150 pages of in-depth technical detail with comprehensive indexes and table of contents. -
Page 11: Chapter 2
PCI LPT & RS232 PCI LPT & RS232 SPECIFICATIONS Introduction. This chapter details the specifications of the PCI LPT & RS232 card and explains how to add the optional serial port to the card. This half-sized card will work happily in any PCI 2.0 or greater compliant PC compatible. -
Page 12: Chapter 2 Page 10
PCI LPT & RS232 Figure 2-1. PCI LPT & RS232 Card Layout. PCI LPT & RS232 Specifications: Dimensions: I/O Connection: LPT port: Chapter 2 Page 10 4.8 x 3.5 in, 120 x 90 mm Serial Port 1: 9 pin Male D type. Optional Serial Port 2: 9 pin Male D type. -
Page 13: Configuring The Pci Lpt & Rs232 Card
PCI LPT & RS232 Configuring The PCI LPT & RS232 Card. PCI cards, by definition, require no hardware configuration and can be installed "directly from the box". Figure 2-2. 9 Pin D Connector Port Pinouts. Parallel Printer Port Configuration. On the PCI LPT & RS232 card, the parallel printer port is the lower 25-pin connector on the card. -
Page 14: Hardware Installation
PCI LPT & RS232 Hardware Installation. NOTE: Always turn the computer OFF before installing or removing any interface board..!!! STEP 1: Before the PC card can be installed the power to the PC must be switched off and for additional safety it is recommended that the mains supply plug is removed from the PC itself. -
Page 15: Problems
PCI LPT & RS232 STEP 6: Now replace the system units cover by carefully sliding it down and back over the system unit. Replace the cover mounting screws. STEP 7: After attaching all the monitor and keyboard cables, power up the PC. Do not forget the mains power cable! The PC should power on in the normal way. -
Page 16: Chapter 2 Page 14
PCI LPT & RS232 Specifications Figure 2-6 Installation of Serial Port 2. Chapter 2 Page 14... -
Page 17: Chapter 3
PCI LPT & RS232 PCI LPT AND RS232 SOFTWARE CONFIGURATION GUIDE Introduction. This section contains the installation procedures of the PCI LPT and RS232 card, with the Windows 95/98 Windows 3.x and DOS operating systems. The setup procedures in this chapter assume that your PC has only one serial port present. -
Page 18: Chapter 3 Page 16
PCI LPT & RS232 Insert the Windows 95 installation disk into an appropriate drive and click ’Next’. The Wizard should then display something similar to following: Click Finish. Chapter 3 Page 16 Software Guide... -
Page 19: Chapter 3 Page 17
PCI LPT & RS232 A "Copying Files…" window should now appear. Click 'OK' when it asks you to insert the disk. After copying the file, Windows 95 will then detect each of the serial ports in turn and install them as communications ports; in the case of the PCI LPT and RS232 it will also detect the parallel port, and then install it as a printer port. -
Page 20: Card Settings In Windows 95 & 98
PCI LPT & RS232 Card Settings In Windows 95 & 98. Select the PCI LPT and RS232 card from the "Multi-Function Adapter" entry in Device Manager and click on properties to view the cards general properties; clicking on the Serial Solutions tab produces: In this window, the COM (and LPT) port assignment may be changed, simply by selecting a new COM port value from the pull down menu... -
Page 21: Port Settings In Windows 95 & 98
PCI LPT & RS232 Port Settings In Windows 95 & 98. Double clicking on a Communications Port that belongs to a PCI LPT and RS232 card will display general properties window for that port (in this case COM2). Selecting the Port Settings tab produces: Settings available in these windows are: 1. -
Page 22: Chapter 3 Page 20
PCI LPT & RS232 6. Advanced - clicking on this will display the following window: Settings available in this window are: Use FIFO Buffers - turns the selected ports FIFO buffer on or off. It is strongly recommended that the FIFO for both ports is left enabled. -
Page 23: Chapter 3 Page 21
PCI LPT & RS232 Defaults: when clicked this button restores the advanced settings for the selected port to: 7. Restore Defaults - when clicked, resets the selected COM port to the following values: Baud Rate: Data Bits: Parity: Stop Bits: Flow Control: Chapter 3 Page 21 Use FIFO Buffers:... -
Page 24: Configuring Ports In Windows 3.X
PCI LPT & RS232 Configuring Ports In Windows 3.x The Windows 3.x installation procedure consists of two steps after the PCI LPT & RS232 CARD is inserted: 1. Determining the resources that the PCI LPT & RS232 Card has claimed. 2. -
Page 25: Windows 3.X Software Installation
PCI LPT & RS232 Software Guide Windows 3.x Software Installation. Place the supplied Serial Solutions for Windows 3.x disk in a suitable drive. From File Manager choose ’Run’ and enter a:\setup (where a: is the path to the floppy drive with the installation disk). * Click OK, the Setup Program Main Screen is displayed: By default, all component options will be installed, selecting the "Del AT’... -
Page 26: Serial Port Installation
PCI LPT & RS232 Software Guide When you have made your choice of Component Options click Continue and when the setup program has finished select the Done button. Note: If the Serial Port driver options has been selected, after the setup program has finished, Windows will display a restart message - answer Yes and Serial Solutions will be ready to run upon Windows restarting. -
Page 27: Chapter 3 Page 25
PCI LPT & RS232 Software Guide To add a COM port: Click on the add button and a Window similar to the following will be displayed: In Standard Settings: In the COM Base field, enter the value 0140. Note: COM ports are defined with an i/o address range, which in this case, begins at 0140 and all subsequent ports have an i/o address that is 8 higher than the previous. -
Page 28: Configuring The Com Ports
PCI LPT & RS232 Software Guide When you have finished, click on OK. A restart message will be displayed; to save time restart only when both ports have been added and correctly configured. Repeat the above process to add the second COM port of the PCI LPT &... -
Page 29: Deleting Ports In Windows
PCI LPT & RS232 Note: A port that has been added has the default values of. Baud Rate: 9600 Data Bits: Parity: None top Bits: Flow: None Change the communications Settings in the COM Ports to match the baud rate, parity settings etc. of the remote serial device. Deleting Ports in Windows. -
Page 30: Configuring Ports In Dos
PCI LPT & RS232 Configuring Ports In DOS. The DOS installation procedure consists of two steps after the PCI LPT & RS232 card is inserted: 1. Determining the resources that the PCI LPT & RS232 has claimed. 2. Informing the Serial Solutions DOS device driver of those resources. -
Page 31: Newcom.sys Parameters
PCI LPT & RS232 NEWCOM.SYS Parameters. The NewCOM.SYS device driver included with the PCI LPT & RS232 driver software is used to set up the card in DOS and has the following syntax: PCI LPT & RS232 NEWCOM.SYS /A port address, /I IRQ, range /B number buffer /S buffer /H hardware handshake Where /A port address specifies COM port number followed by a hexadecimal address in the form /Ax,y where x is COM port range... -
Page 32: Configuring And Installing Newcom.sys
PCI LPT & RS232 are ignored. The RTS output line is set true just in case the external serial device needs a true signal. Type 4 3 Wire Handshake - Really no handshake at all since the PC transmits irrespective of the handshake lines. -
Page 33: Irq, Range
PCI LPT & RS232 Software Guide IRQ, Range. /I 11,5-6 11 is the IRQ and since the COM port range is COM5 COM6 range is entered as 5-6. Number Buffer. Six buffers are defined, though only four ports are in use this is because buffers in DOS are assigned in a sequential order from COM1. - Page 34 Index 16450 / 16550 ... 4, 6, 9 asynchronous ... 9 baud / baud rate... 5, 6, 9 buffer / buffered... 5, 6, 9 cable... 6, 13 Changing COM numbers in Windows 95 ... 19 command ... 5 Configuring ports in Windows 95 & 98... 20 connectors ...
- Page 35 RS422 / RS485 ... 4 RTS ... 5, 9 RXD ... 9 serial port ...1, 4, 5, 6, 7, 9 shared interrupt ... 7 speed... 9 technical... 8 TXD... 9 Windows... 2, 4, 6, 4, 7 INDEX...
