PCI VELOCITY / OPTO ISO RS422/485
Configuring Ports In Windows 3.x
The Windows 3.x installation procedure consists of two
steps after the PCI RS422/485 card is inserted:
1. Determining the resources that the PCI RS422/485 card has
claimed.
2. Informing Windows 3.x of those resources.

Determining PCI RS422/485 Resources.

Insert the card into a PC, as described in Chapter 2.
Run BBCARDS.EXE, from the supplied DOS utility disk titled
"Serial Solutions Utility Disk" by typing the following:
% @4'-@&&'%6(7
Where A:\ is the drive containing the supplied disk.
BBCARDS.EXE will return a string that looks similar to
the following (values contained in the string may differ in
individual PC's due to resource availability):
Velocity users:
w‚ˆs††‰„ˆÂ€w‚sÂ!!
"‡sˆ‡ÂƒtÂ!&%% qƒ„iˆwp€s†suw‡ˆs†‡
Opto Iso users:
w‚ˆs††‰„ˆÂ€w‚sÂ!!
"‡sˆ‡ÂƒtÂ!&%% qƒ„iˆwp€s†suw‡ˆs†‡
Note down IRQ and I/O address, which in this case are:
The IRQ = 11
The I/O address = 0140
Software Configuration
EQÂirr†s‡‡Â !$
EQÂirr†s‡‡Â !$
Chapter 3 Page 29
