Software Configuration
Note: A port that has been added has the default values of:
Baud Rate:
Data Bits:
Parity:
top Bits:
Flow:
Change the communications Settings in the COM Ports to
match the baud rate, parity settings etc. of the remote serial device.
Deleting Ports in Windows.
The Delete button can be used to discard the entries of
ports that have been removed from the system.
Note. Never try to leave out a serial port number when
using the delete button, because Windows may automatically shift
serial port numbers which results in a mis-match of settings in the
Serial Ports Applet (COM1-COM4 only).
Restarting Windows.
Whenever certain values have been entered or changed in
the hardware settings window, a message prompting to restart
Windows will appear. Only after having made ALL the necessary
changes restart Windows so that the new settings come into effect.
Chapter 3 Page 34
PCI VELOCITY / OPTO ISO RS422/485
9600
8
None
1.0
None
