PCI VELOCITY / OPTO ISO RS422/485
All COM ports present will be listed under the entry "Ports
(COM & LPT)." The above screenshots indicates that COM2 - 4
and COM7 and above are not installed, and therefore may be used.
PCI RS422/485 Port Settings In Windows 95 & 98.
Double clicking on a Velocity RS485 Port entry from the
entry "Ports (Com & LPT)" branch in Device Manager will the
display general properties window for the selected port (in this
case COM5).
Selecting the Port Settings tab produces:
Settings available in this window are:
1. Baud Rate - determines the baud rate at which the
selected port operates, the maximum value available is
dependant upon the Maximum Baud Rate Setting (see
below.)
2. Data Bits.
3. Parity.
4. Stop Bits.
5. Flow Control.
6. Maximum Baud Rate Setting - four values are
available, which selects the maximum baud rate at
which the port may operate. Table 3-1, below, indicates
Software Configuration
Change to suit remote device.
Chapter 3 Page 19
