PCI VELOCITY / OPTO ISO RS422/485
Figure 2-1. PCI VELOCITY RS422/485 Card Layout.
P
O
R
T
#1
P
O
R
T
#2
RS485 Multiplex jumper block
PCI VELOCITY RS422/485 Specifications:
Dimensions:
I/O Connection:
Weight:
TX/RX1+
TX/RX1-
TX/RX2-
TX/RX2+
5 x 3 in, 120 x 85 mm
Serial Port 1: 9 pin Male D type.
Serial Port 2: 9 pin Male D type.
95g
