- Page 1 %UDLQ%R[HV ! #% 1.1 E D IT IO N JA N U A R Y 20 00...
-
Page 2: Level
PCI VELOCITY RS422/485 AUTOGATING These products conform to the following standards: CE standard: EN55022:1987 Class B IEC 801-2: IEC 801-3: IEC 801-4: PCB: IEC 249-2-5 NEMA L1 1-10 DIN 40802 UTE C 93-711 BS 4584 MIL P-13949E UL Approved to 94 V0 TIA /EIA: 485 A (1995) ,423 B (1996) Year 2000:... -
Page 3: The Layout Of This Manual
PCI VELOCITY RS422/485 AUTOGATING OUTLINE CONTENTS Chapter 1 - Supplied Serial Solution Software. Chapter 2 - PCI Velocity RS422/485 Specifications. Chapter 3 - PCI Velocity RS422/485 Software Configuration Guide. Chapter 4 - Additional RS422/RS485 Information. The Layout Of This Manual Chapter 1 - Serial Solution Software , is an overview of this companion software package for our range of serial port cards. -
Page 4: Table Of Contents
TABLE OF CONTENTS CHAPTER 1 SERIAL SOLUTIONS SOFTWARE...6 Introduction..6 Introducing Serial Solution Software..6 Serial Solutions For DOS..6 Serial Solutions For Windows 3.x... 8 Serial Solutions For Windows 9x... 8 Serial Solutions For Windows NT..9 Complete Documentation and Technical Backup... - Page 5 Deleting Ports in Windows..26 Restarting Windows..26 95 I INDOWS NSTALLATION Card Settings In Windows 95... 31 PCI RS422/485 Port Settings In Windows 95... 32 98/M INDOWS ILLENIUM Card Settings In Windows 98/Millenium..41 Port Settings In Windows 98/Millenium..42 NT 4.0 I INDOWS Software Installation...
-
Page 6: Chapter 1 Serial Solutions Software
PCI 1 Port RS422/485 SERIAL SOLUTIONS SOFTWARE Introduction. This chapter is a brief description of the Serial Solutions software package; this can also be purchased SEPARATELY and is available from YOUR DEALER. Introducing Serial Solution Software. The perfect partner for any Serial Port is Serial Solutions Software! Serial Solutions is a fully featured suite of programs designed to squeeze the most from PC serial communications. -
Page 7: Chapter 1 Page 7
PCI 1 Port RS422/485 Accessible from all DOS languages, it is the heart of the Serial Solution. implementing both hardware handshaking using any combination of the DTR, DSR, CTS, RTS, and DCD lines, and a software handshake using the XON/XOFF protocol. NewCOM24.sys A device driver providing support for 24 ports. -
Page 8: Serial Solutions For Windows 3.X
PCI 1 Port RS422/485 the particular IRQ line. The program correctly identifies the UART type by employing the built in loop back capability of the PC serial port chip, a full test of the baud rate generator, transmitting and receiving buffer, parity enable and start stop bit is performed. -
Page 9: Serial Solutions For Windows Nt
PCI 1 Port RS422/485 sscardui.dll ssportui.dll The device manager configuration DLLs and… ssenum.vxd ssv485.vxd ...the virtual device drivers providing the shared ssvel.vxd interrupt handlers and dispatch routines etc for the ssmult.vxd various Serial Solutions serial cards. ssm485.vxd Serial Solutions For Windows NT. Windows NT has an improved communication API and directly supports up to 255 ports. -
Page 10: Chapter 2 Pci 1 Port Velocity Rs422/48
PCI 1 Port RS422/485 PCI 1 PORT VELOCITY RS422/48 HARDWARE SETUP Introduction. This chapter details the specifications of the PCI 1 Port Velocity RS422/485 card and explains how to configure the RS485 Multiplex jumpers present on this card. This half-sized card will work happily in any PCI 2.0 or greater compliant PC compatible. -
Page 11: General Pci Rs422/485 Serial Port Features
PCI 1 Port RS422/485 General PCI RS422/485 Serial Port Features Clock Input: Drivers: High Level Voltage: Low Level Voltage: High Level Current: Low Level Current: Receivers: Difftial I/P threshold: 200mV max. Hysteresis: Input Impedance: Autogating. Multitasking operating systems, like Windows 95, Windows NT, OS/2 and UNIX, cannot successfully use the RTS line to control the gating of the PC’s transmitter. -
Page 12: Chapter 2 Page 12
PCI 1 Port RS422/485 Figure 2-1. PCI 1PORT VELOCITY RS422/485 Layout. RX1- MULTIPLEX RS485 RX1+ RS485 Multiplex jumper block PCI 1 PORT VELOCITYRS422/485 Specifications: Dimensions: I/O Connection: Weight: Figure 2-3. 9 Pin D Connector Port Pinouts. 4.8 x 2.5 in, 122 x 63.5 mm Serial Port 1: 9 pin Male D type. -
Page 13: Configuring The Pci Rs422/485 Cards
PCI 1 Port RS422/485 Configuring The PCI RS422/485 Cards. PCI cards require no hardware configuration for IRQ and address allocation - this is done automatically at start up by the PC. However, the PC 1 Port Velocity RS422/485 has a set of jumpers for configuration of RS485 multiplex modes, details of configuring these jumpers is shown below. -
Page 14: Hardware Installation
PCI 1 Port RS422/485 Hardware Installation. STEP 1: Before the PC card can be installed the power to the PC MUST be switched OFF, and to ensure extra safety, the power lead removed from the PC. STEP 2: Remove the PC case. Step 3 - Removing Blanking Cover Step 4 - Inserting The PCI Serial Card. -
Page 15: Problems
PCI 1 Port RS422/485 down and back over the system unit. Replace the cover mounting screws. STEP 7: After attaching all the monitor and keyboard cables, power up the PC. Do not forget the mains power cable! The PC should then power on in the normal way. -
Page 16: Software Configuration Guide
PCI 1 Port RS422/485 PCI 1 PORT VELOCITY RS422/485 SOFTWARE CONFIGURATION Introduction. This section contains the installation procedures of the PCI VELOCITY RS422/485 card, with the DOS, Windows 3.x Windows 95, Windows 98/Millennium, Windows NT and Windows 2000 operating systems. The setup procedures in this chapter assume that your PC has only one serial port present. -
Page 17: Newcom.sys Parameters
PCI 1 Port RS422/485 1 set of 16550-compatible registers are at I/O address 0140 Baud clock control is at I/O address 02d0 Write 0xf6 for /8 (default), 0xf2 for /4, 0xd6 for /2, 0xd2 for /1. Note down IRQ and I/O which in this case: The IRQ = 11 The I/O address = 0140 NEWCOM.SYS Parameters. -
Page 18: Chapter 3 Page 18
PCI 1 Port RS422/485 COM port or ports and hs selects handshake type. Handshake types available are: Type 1 RS422 RTS/CTS - The PC only transmits when CTS is input true. When the PC is able to receive its sets RTS output true. The DSR and DCD inputs are ignored. -
Page 19: Configuring And Installing Newcom.sys
PCI 1 Port RS422/485 Configuring And Installing NEWCOM.SYS To load the Serial Solutions for DOS device driver an entry needs to be added to the CONFIG.SYS file. Any simple text editor, EDIT for example, can edit the CONFIG.SYS file for example. The installation procedure given below is for a PCI RS422/485 as COM The parameter required by the NEWCOM.SYS driver are those returned by the BBCARDS.EXE application earlier. -
Page 20: Modifying Command Line Parameters
PCI 1 Port RS422/485 Hardware Handshaking. /H,4 Type 4, 3 Wire Handshake selected for all ports. Type 4, 3 Wire Handshake selected for all ports. Modifying Command Line Parameters. When "assembled" the NEWCOM.SYS command line looks like… DEVICE=NEWCOM.SYS /A5,0140 /I 11,5 /B5 /S 512 /H,4 …and should be entered into the CONFIG.SYS file. -
Page 21: Windows 3.X Installation
PCI 1 Port RS422/485 Windows 3.x Installation. The Windows 3.x installation procedure consists of two steps after the PCI RS422/485 card is inserted: 1. Determining the resources that the PCI RS422/485 card has claimed. 2. Informing Windows 3.x of those resources. Determining PCI RS422/485 Resources. -
Page 22: Windows 3.X Software Installation
PCI 1 Port RS422/485 Windows 3.x Software Installation. Place the supplied Serial Solutions CDROM in a suitable drive. From File D:\diskimg\sswin3x\setup (where D: is the path to the CDROM drive Containing the disk). Click OK, the Setup Program Main Screen is displayed: By default, all component options will be installed, selecting the "Del All"... -
Page 23: Serial Port Installation
PCI 1 Port RS422/485 When you have made your choice of Component Options click Continue and when the setup program has finished select the Done button. Note: If the Serial Port driver options has been selected, after the setup program has finished, Windows will display a restart message - answer Yes and Serial Solutions will be ready to run upon Windows restarting. -
Page 24: Chapter 3 Page 24
PCI 1 Port RS422/485 The following dialogue will be displayed: To add a COM port: Click on the add button and a Window similar to the following will be displayed: In Standard Settings: In the COM Base field, enter the value 0140. Note: COM ports are defined with an i/o address range, which in this case, begins at 0140 and all subsequent ports have an i/o address that is 8 higher than the... -
Page 25: Configuring The Com Ports
PCI 1 Port RS422/485 Note: The values used in the above section were those returned by the BBCARDS program, as described in the above section. When you have finished, click on OK. A restart message will be displayed; to save time only restart when both ports have been added and correctly configured. -
Page 26: Deleting Ports In Windows
PCI 1 Port RS422/485 Note: A port that has been added has the default values of: Baud Rate: Data Bits: Parity: top Bits: Flow: Change the communications Settings in the COM Ports to match the baud rate, parity settings etc. of the remote serial device. Deleting Ports in Windows. -
Page 27: Windows 95 Installation
PCI 1 Port RS422/485 Windows 95 Installation. To obtain a trouble free mix-and-match of the COM ports: Switch off your computer, insert your PCI RS422/485 card into a free PCI slot, as described in the section "Hardware Installation" in Chapter 2, and switch your computer on again. During the booting process, Windows 95 will detect the PCI Velocity RS422/485, but will display it simply as a "PCI CARD", and you will briefly see a message box to this effect. -
Page 28: Chapter 3 Page 28
PCI 1 Port RS422/485 Software Setup The Wizard should then display the following: Click Other Locations In the location space type <drive>:\diskimg\sswin9x where drive is the appropriate letter for your CDROM drive Click OK Chapter 3 Page 28... -
Page 29: Chapter 3 Page 29
PCI 1 Port RS422/485 Click Finish After copying the file, Windows 95 will then detect each of the serial ports in turn and install them as communications ports. Using the right-hand mouse button click on the My Computer icon on your desktop. Click on Properties. Chapter 3 Page 29 Software Setup... -
Page 30: Chapter 3 Page 30
PCI 1 Port RS422/485 Software Setup Click on the Device Manager tab When the "Device Manager" is viewed the PCI 1 port Velocity R422/485 card will appear under the "Multi-function adapters" branch. Also, a Velocity RS485 Port will appear under the "Ports (COM &... -
Page 31: Card Settings In Windows 95
PCI 1 Port RS422/485 Card Settings In Windows 95 Select the PCI Velocity RS422/485 card from the "Multi- Function Adapter" entry in Device Manager serial and click on properties to view the cards general properties. Click on the Serial Solutions tab Solutions tab produces. The I/O address and interrupt are assigned to the card by the "Plug and play"... -
Page 32: Pci Rs422/485 Port Settings In Windows 95
PCI 1 Port RS422/485 In this window, the COM port assignment may be changed, simply by selecting a new COM port value from the pull down menu relevant to the port. However, COM port usage other than those for the PCI 1 Port Velocity RS422/485 card itself are not checked, so it is advisable to first check which COM ports are in use - port availability can be checked by viewing the Device Manager: All COM ports present will be listed under the entry "Ports... -
Page 33: Chapter 3 Page 33
PCI 1 Port RS422/485 Selecting the Port Settings tab produces: Settings available in this window are: 1. Baud Rate - determines the baud rate at which the selected port operates, the maximum value available is dependant upon the Maximum Baud Rate Setting (see below.) 2. -
Page 34: Maximum Baud Rate Settings
PCI 1 Port RS422/485 Maximum Baud Rate Settings. 115200 1200 1800 Selectable 2000 Baud 2400 Rates 3600 4800 7200 9600 19200 38400 57600 115200 Note: Many serial comms applications will not actually register the ports as running at baud rates of above 115200. 7. -
Page 35: Chapter 3 Page 35
PCI 1 Port RS422/485 Clicking on the Serial Solutions tab will display: Settings available in this window are: 1. FIFO Settings. Enable FIFO - turns the selected ports FIFO buffer on or off. It is strongly recommended that the FIFO for both ports is left enabled. -
Page 36: Chapter 3 Page 36
PCI 1 Port RS422/485 options may be selected: Off (Default) - This will turn off automatic flow control. (If you have no data transfer problems then selecting this option is fine.) RTS/CTS - This will use the RTS and CTS lines for automatic hardware flow control. -
Page 37: Windows 98/Millenium Installation
PCI 1 Port RS422/485 Windows 98/Millenium Installation. To obtain a trouble free mix-and-match of the COM ports: Switch off your computer, insert your PCI RS422/485 card into a free PCI slot, as described in the section "Hardware Installation" in Chapter 2, and switch your computer on again. During the booting process, Windows 98 will detect the PCI Velocity RS422/485, but will display it simply as a "PCI CARD", and you will briefly see a message box to this effect. -
Page 38: Chapter 3 Page 38
PCI 1 Port RS422/485 The Wizard should then display the following: Select Search for the best driver for your device. Click Next Click Specify a location In the location space type <drive>:\diskimg\sswin9x where drive is the appropriate letter for your CDROM drive Click Next Chapter 3 Page 38 Software Setup... -
Page 39: Chapter 3 Page 39
PCI 1 Port RS422/485 Click Next Click Finish After copying the file, Windows 95 will then detect each of the serial ports in turn and install them as communications ports. Chapter 3 Page 39 Software Setup... -
Page 40: Chapter 3 Page 40
PCI 1 Port RS422/485 Software Setup Using the right-hand mouse button click on the My Computer icon on your desktop. Click on Properties. Click on the Device Manager tab When the "Device Manager" is viewed the PCI 1 port Velocity R422/485 card will appear under the "Multi-function adapters"... -
Page 41: Card Settings In Windows 98/Millenium
PCI 1 Port RS422/485 Card Settings In Windows 98/Millenium. Select the PCI Velocity RS422/485 card from the "Multi- Function Adapter" entry in Device Manager serial and click on properties to view the cards general properties. Click on the Serial Solutions tab Solutions tab produces. The I/O address and interrupt are assigned to the card by the "Plug and play"... -
Page 42: Port Settings In Windows 98/Millenium
PCI 1 Port RS422/485 In this window, the COM port assignment may be changed, simply by selecting a new COM port value from the pull down menu relevant to the port. However, COM port usage other than those for the PCI 1 Port Velocity RS422/485 card itself are not checked, so it is advisable to first check which COM ports are in use - port availability can be checked by viewing the Device Manager: All COM ports present will be listed under the entry "Ports... -
Page 43: Chapter 3 Page 43
PCI 1 Port RS422/485 Selecting the Port Settings tab produces: Settings available in this window are: 8. Baud Rate - determines the baud rate at which the selected port operates, the maximum value available is dependant upon the Maximum Baud Rate Setting (see below.) 9. -
Page 44: Chapter 3 Page 44
PCI 1 Port RS422/485 Maximum Baud Rate Settings. 115200 1200 1800 Selectable 2000 Baud 2400 Rates 3600 4800 7200 9600 19200 38400 57600 115200 Note: Many serial comms applications will not actually register the ports as running at baud rates of above 115200. 14. -
Page 45: Chapter 3 Page 45
PCI 1 Port RS422/485 Clicking on the Serial Solutions tab will display: Settings available in this window are: 5. FIFO Settings. Enable FIFO - turns the selected ports FIFO buffer on or off. It is strongly recommended that the FIFO for both ports is left enabled. -
Page 46: Chapter 3 Page 46
PCI 1 Port RS422/485 options may be selected: Off (Default) - This will turn off automatic flow control. (If you have no data transfer problems then selecting this option is fine.) RTS/CTS - This will use the RTS and CTS lines for automatic hardware flow control. -
Page 47: Windows Nt 4.0 Installation
PCI 1 Port RS422/485 Windows NT 4.0 Installation. Microsoft Windows NT Provides built in support for 255 standard serial ports. To setup your PCI RS422/485 serial card you should follow these steps. Please note that to change any kind of hardware configuration under Windows NT you must be logged in as a user with Administrator level privileges, if you do not have these please contact your system administrator. -
Page 48: Examining Card Configuration
PCI 1 Port RS422/485 Software Setup Examining Card Configuration. Go to Control Panel (Start/Settings/Control Panel) and double click on Serial Solutions PCI: You will be presented with a Serial Solutions PCI Port Configuration window: Chapter 3 Page 48... -
Page 49: Configuring Ports
PCI 1 Port RS422/485 Configuring Ports. To view the settings of a port, select it and click on settings, and then click on the resources tab: Settings available in this window are: Settings available in this window are: 1. Baud Rate - determines the baud rate at which the selected port operates, the maximum value available is 921,600 (1 Megabaud.) Note: Many serial comms applications will not actually register the ports as... -
Page 50: Advanced Port Settings
PCI 1 Port RS422/485 7. Restore Defaults - when clicked, resets the selected COM port to the following values: Baud Rate: Data Bits: Parity: Stop Bits: Flow Control: Advanced Port Settings. When the Advanced button of Port Settings is selected the following dialogue is displayed: Settings available in this window are: 1. -
Page 51: Chapter 3 Page 51
PCI 1 Port RS422/485 Receive Buffer - These settings allow the selection of a receiver FIFO trigger setting. Selecting a low value will allow the interrupt to be serviced quicker, which is good for slow machines. If you have a fast machine, setting a high value will give you more time for multi-tasking operations. -
Page 52: Uninstalling Serial Solutions Pci
PCI 1 Port RS422/485 Force CTS True, determines whether the CTS handshake signal is INPUT from the external serial device or is permanently forced true on the card. The serial ports own RTS OUTPUT handshake signals are always taken out to the serial port connector. -
Page 53: Chapter 4 Additional Rs422/485 Operation
PCI 1 Port RS422/485 ADDITIONAL RS422/485 The RS422 Standard. The RS422 standard defines a serial communications standard. RS422 is a high speed and/or long distance data transmission. Each signal is carried by a pair of wires and is thus a differential data transmission system. -
Page 54: Terminating Impedance's
PCI 1 Port RS422/485 more than one device may transmit data, the RTS line is used as transmit enable signal, so preventing contention between talkers. Line Length 400 Feet = 122m 4000 Feet = 1219m Terminating Impedance’s. RS422 and RS485 lines should be terminated at the end of the main branch of the RECEIVER, in the cables characteristic impedance. -
Page 55: Fail Safe Open Circuit Detection
PCI 1 Port RS422/485 Fail Safe Open Circuit Detection Open circuit is when there are no drivers on the circuit. This occurs by design in party line multi driver/receiver systems and unintentionally when the twisted pair line is accidentally cut or disconnected or the transmitting device fails. -
Page 56: Rs422 Serial Port Cables
PCI 1 Port RS422/485 This RS422 arrangement allows data to be transmitted and received simultaneously since each signal has its own data cable pair. In addition, the receiver can set RTS true so telling the transmitter on its CTS input that the receiver is ready to accept data. -
Page 57: Rs485 Operation
PCI 1 Port RS422/485 ii.) USE BELDEN TYPE 9729 etc. see above. iii.) RS485 Gating & Multiplex Jumpers as Factory Set. RS485 Operation. The RS485 standard is intended for up to 32 driver receiver pairs on the bus. The line drivers used in the Serial Solutions RS422/485 card are designed to work correctly in both RS422 and RS485 systems. -
Page 58: Rs485 One Talker - Many Listeners, Half Duplex
PCI 1 Port RS422/485 communications. Use screened twisted pair Belden cable 9729 and 9829, UL type 2493 and 2919 or IBM Part No 4716748 cable to make the RS485 connection. Terminate the twisted pair cable at either end in its characteristic impedance, which for the Belden 9729 cable is 120 Ohms. -
Page 59: Rs485 Many Talkers- Many Listeners, Half Duplex
PCI 1 Port RS422/485 Figure 4-3 Half Duplex Settings of RS485 Multiplex Both jumpers shorted, causing the RXD- & TXD- and the RXD+ & TXD+ signals to short together at the 9-pin connector. RS485 Many Talkers- Many Listeners, Half Duplex. Another popular RS485 layout is for multiple talkers and multiple listeners. -
Page 60: Rs485 Many Talkers- Many Listeners, Full Duplex
PCI 1 Port RS422/485 RS485 Many Talkers- Many Listeners, Full Duplex. The RS485 many talkers, many listeners, Full Duplex system can be used when all the RS485 devices have separate Transmit and Receive channels. There is NO multiplexing of the TXD and RXD signals on the same device. -
Page 61: Optional Grounding Arrangements
PCI 1 Port RS422/485 Software Setup TXD channel, and disables its TXD drivers. The other RS485 devices remain in the receive only mode when they are not being addressed, they do not transmit any data at all. Figure 4-5 gives the jumper settings for the serial card in the RS485 Full Duplex mode. -
Page 62: Chapter 3 Page 62
PCI 1 Port RS422/485 Figure 4-7 - Optional Grounding Arrangements For A PCI RS422/485 Card. Configuration A) Configuration B) Configuration A) connected to protective ground, at one point only by a 100 resistor with a power dissipation rating of 1/2W. An additional provision may be made for the resistor to be bypassed with a strap to connect signal common and protective ground directly together when specific installation conditions necessitate. -
Page 63: Index
PCI 1 Port RS422/485 Software Setup Index 1 Megabaud ...10 115200 Baud...34, 44 16450 / 16550...6, 10 460800 Baud...34, 44 921600 Baud...34, 44 asynchronous ...10 Autogating ...10, 11 baud / baud rate ...7, 8 BBCARDS.EXE...16, 18, 21 Belden...66 bits ...64 buffer ...65 Buffer...19 buffer / buffered...7, 8, 10... - Page 64 PCI 1 Port RS422/485 Software Setup interrupts...8 jumper...66, 67, 68, 69, 70 last ...68 loop back ...8 Maximum Baud Rate...33, 34, 43, 44 Megabaud ... See 921600 baud mode ...7, 70 open circuit ...64 parity...7, 8 party line...64, 68 port / ports ...6, 7, 8, 10, 15, 47, 53, 63 Port Address ...18 protocol...7, 66 receive ...13, 67, 68, 69, 70...
