ELC Distributed I/O Adapters
Stop bit
Explanation
0: 1 Stop bit
1: 2 Stop bits
0000 (0)
Content
0001 (1)
0010 (2)
Content
0x02
0x03
BR#6: Address
For assigning or reading the Modbus serial address of the ELC-CAENET. The address will be
displayed in the message display after being set up. Range: 1 ~ 247.
BR#7: Number of Digita l Input Points
Read the number of digital input points from BR#7. Range: 0 ~ 256. Max. I/O points: 256. The
number of input points is autiomatically detected by the ELC-CAENET based on the connected
I/O cards.
BR#8: Number of D igita l Out put Points
Read the number of digital output points from BR#8. Range: 0 ~ 256. Max. I/O points: 256. The
number of output points is autiomatically detected by the ELC-CAENET based on the
connected I/O cards.
BR#9: Error Code
Description:
Error code = 0 refers to no error occurring.
Code
F0
Returning to default setting
F1
ELC-CAENET being powered
F2
Power supply in low voltage
F3
Internal error. Manufacturing error.
F5
Network connection error
78
b7
7-N-1
0011 (3)
8-N-1
0110 (6)
7-O-1
0111 (7)
Indication
For More Information visit: www.eaton.com
b6 ~ b5
Parity bit
00 : None parity bit
01 : Odd parity bit
11 : Even parity bit
8-O-1
1000 (8)
7-E-1
1001 (9)
8-E-1
1010 (A)
b8 ~ b15
Explanation
Modbus RTU Master
Modbus ASCII Master
How to correct
--
--
Check if the power supply of the module is functioning
normally.
1. Check if the settings of local logic are incorrect.
2. Re-power ELC-CAENET. If the error still exists, try
step 3.
3. Reset ELC-CAENET. If the error still exists, send
the module back to the manufacturer for repair.
Check if ELC-CAENET is properly connected to the
b4
Data bit
0 : 7 Data bits
1 : 8 Data bits
7-N-2
1011 (B)
8-O-2
8-N-2
1110 (E)
7-E-2
7-O-2
1111 (F)
8-E-2
MN05002003E
