Transmission cable
Serial communication interface (COM2)
Interface
Transmission method
Transmission distance
Communication speed
Communication format
Communication
protocol
Environment
Noise immunity
Operation
Storage
Shock/vibration
immunity
Certificates
Electrical specification
Power supply voltage
Power fuse capacity
Power consumption
Insulation voltage
Weight
MN05002003E
ELC-CBPCELC3
3 PIN feed-through terminal
RS-485
4,000 ft (@19.2K)
110, 150, 300, 600, 1,200, 2,400, 4,800, 9,600, 19,200,
38,400, 57,600, 115,200 bps
Stop bit: 1, 2; Parity bit: None, Odd, Even; Data bit: 7, 8
Modbus ASCII、Modbus RTU
ESD (IEC 61131-2, IEC 61000-4-2): 8KV Air Discharge
EFT (IEC 61131-2, IEC 61000-4-4): Power Line:±2KV, Digital
Input: ±2KV,
Communication I/O: ±2KV
RS (IEC 61131-2, IEC 61000-4-3): 80MHz ~ 100MHz, 10V/m.
1.4GHz ~ 2.0GHz, 10V/m
Conducted Susceptibility Test (EN61000-4-6, IEC61131-2 9.10):
150kHz ~ 80MHz, 3V/m
Surge Test (Biwave IEC61132-2, IEC61000-4-5): Power line
0.5KV DM, Ethernet 0.5KV CM, RS-485 0.5KV CM
0ºC ~ 55ºC (temperature), 50 ~ 95% (humidity), pollution
degree 2
-25ºC ~ 70ºC (temperature), 5 ~ 95% (humidity)
International standards: IEC61131-2, IEC 68-2-6 (TEST
Fc)/IEC61131-2 & IEC 68-2-27 (TEST Ea)
24VDC (-15% ~ 20%) (with DC input polarity reverse
protection)
1.85A/30VDC, Polyswitch
2W
500VDC
116g
For More Information visit: www.eaton.com
ELC Distributed I/O Adapters
71
