ELC Distributed I/O Adapters
BR#
Attribute
1
R
Firmware version
Release date of
2
R
the version
Start/Stop PLC
3
R/W
function
4
Reserved
COM2
5
R/W
communication
settings
6
R/W
Address
Number of DI
7
R
points
Number of DO
8
R
points
9
R
Error code
10
Reserved
Communication
11
R/W
time-out
Communication
12
R/W
delay time
TCP connection
13
R/W
idle time
14 ~ 22
Reserved
Number of
23
R
analog I/O
modules
ID of the 1st
24
R
analog I/O
module
ID of the 2nd
25
R
analog I/O
module
ID of the 3rd
26
R
analog I/O
module
ID of the 4th
27
R
analog I/O
module
ID of the 5th
28
R
analog I/O
module
ID of the 6th
29
R
analog I/O
module
ID of the 7th
30
R
analog I/O
module
76
Content
the current firmware verision in hex, e.g. V1.2 is
indicated as high byte = 0x01 and low byte =
0x20.
the data in decimal form. 10,000s digit and
1,000s digit are for "month"; 100s digit and 10s
digit are for "day". For 1s digit: 0 = morning; 1 =
afternoon.
Example: 12191 indicates the version released
in the afternoon of December 19.
RS-485 communication settings. Please refer to
the table of baud rate setting and
communication format setting.
For setting up the station address
Range: 0 ~ 256
Range: 0 ~ 256
Displaying the errors. Please refer to the table
of error codes.
For setting up the communication time-out (ms)
in Modbus TCP mode.
For setting up the minimum interval time
between every communication datum.
For setting up idle time for TCP communication.
Unit: second
Max. 8
ID of the 1st analog I/O module
ID of the 2nd analog I/O module
ID of the 3rd analog I/O module
ID of the 4th analog I/O module
ID of the 5th analog I/O module
ID of the 6th analog I/O module
ID of the 7th analog I/O module
For More Information visit: www.eaton.com
Explanation
Default Latched
YES
YES
NO
NO
H'0368
YES
K'1
YES
NO
NO
NO
NO
K'5000
YES
K'0
YES
K'30
YES
NO
NO
NO
NO
NO
NO
NO
NO
NO
MN05002003E
