Inputs
CAN Bus
VCI CAN Input
CAN Bus Outputs
Bit rate
Identifier type
Data available
Power
Input Voltage range
Current
Environmental and physical
Weight
Size
Operating temperature
Storage temperature
CAN connection for Racelogic modules only
Allows the user to log up to 16 channels of
incoming CAN data from other systems
125, 250, 500 kbit/s and 1 Mbit/s selectable baud rate
Standard 11 bit and Extended 29 bit 2.0 A
Satellites, UTC time, Latitude, Longitude, Speed,
Heading, Altitude, Vertical velocity, Longitudinal and
Lateral acceleration, Distance since reset
6 – 30 V DC
Typically 70 mA
Approx 275 g
105 mm x 85 mm x 30 mm
-10˚C to +60˚C
-40˚C to +85˚C
