Connector 3 - ANTENNA (SMA)

PIN

Center

Chassis

https://racelogic.support//01VBOX_data_loggers/VBOX_Micro/VBOX_Micro_-_User_manual/10_-_VBOX_Micro_PIN_OUTS

Name

-

-

Function

RF Signal / Power for active

antenna

Ground

26
