Connector 1 - POWER (Fischer 2 PIN)

PIN

1

2

https://racelogic.support//01VBOX_data_loggers/VBOX_Micro/VBOX_Micro_-_User_manual/10_-_VBOX_Micro_PIN_OUTS

I/O

I

I

Function

Power+

Ground

Range

6 – 30 V

0 V

24
