06 - VBOX Micro Connecting an Input module
The VBOX Micro can connect to any one of the following Racelogic input modules and then include the data from each
channel in the logged VBO file. The VBOX Micro will automatically log all channels from a connected Input Module
providing that the module is connected before the power is switched on.
Description
8 Channel Thermocouple Interface
8 Channel (10 bit) Analogue
Interface
8 Channel (16 bit) Analogue
Interface
4 Channel Frequency and Pulse
Counter Input Module
Mini Input Module
Yaw Rate Sensor + 2-Axis G
Sensor
Inertial Measurement Unit
Configuring the Input Modules
To configure an input module you must connect the module directly to the computer via a serial cable, the channels
cannot be setup via the USB port on the VBOX Micro. The software required will be VBOX Setup -
which modules support VBOX Setup.
The module can take power from the VBOX Micro both during operation and during configuration.
Part Numbers
RLVBTC8
RLVBADC02
RLVBADC03
RLVBFIM03
RLVBMIM01
RLVBYAW03
RLVBIMU04
