Graduated circle and tape measure:
- Graduation diameter of horizontal circle
- Graduation interval (H)
- Graduation diameter of vertical circle
- Graduation interval (V)
- Graduation interval of microscope scale
- Magnification of the horizontal system
- Magnification of the vertical system
Standard error of angle measurement with one taking:
- horizontal Prof X2
- vertical
Compensator for vertical circle index:
- working range
Optical plummet:
- magnification
- angle of visual field
- range of focusing
Weight and dimensions of the instrument:
- height
- net weight
- weight of packing case

3. COMPLETE SET

Theodolite with removable tribrach, case, lens protector from sunlight, plummet, pin, screwdriver, brush, cleaning flannel-cloth,
desiccant, rain cover.
Prof X2

PROF
94mm
1°
76 mm
1°
1'
68x
65.4x
2" /10"
2" /10"
+/- 2'
2,5х
5°
0.7 m -
∞
207 mm
4.3 kg
3.5 kg
MEASUREMENT FOUNDATION
X2
