The following
Figure 5
The following
Table 5
The following
Figure 6
UM2841 - Rev 1
shows the JTAG connector schema:
Figure 5.
JTAG connector schema
shows the JTAG connector pinout:
Table 5.
JTAG Header 2x7 pins connector pinout
Pin number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
shows the NEXUS SAMTEC ASP-137973-01 connector schema:
UM2841
Connectors
Signal
TDI
GND
TDO
GND
TCK
GND
EVTI
N.C.
PORST
TMS
VDD HV IO MAIN
GND
EVTO
N.C.
page 9/28
