Altronix MaxFit3F8AP Installation Manual page 8

1.25" (31.8mm)
6.25" (158.8mm)
1.25" (31.8mm)
1.50"
(38.1mm)
0.569" (14.5mm)
1.50"
(38.1mm)
1.25" (31.8mm)
1.25" (31.8mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIMaxFit3,5F8AP
- 8 -
MaxFit Enclosure Dimensions (approximate):
20.5" x 16.5" x 6.25" (520.7mm x 419.1mm x 158.8mm)
7.00" (177.8mm)
16.50" (419.1mm)
0.75" (19.1mm)
7.00" (177.8mm)
7.00" (177.8mm)
1.25" (31.8mm)
1.00" (25.4mm)
7.00" (177.8mm)
E27T
1.25" (31.8mm)
1.25" (31.8mm)
1.25" (31.8mm)
1.50" (38.1mm)
1.50" (38.1mm)
1.25" (31.8mm)
1.25" (31.8mm)
1.25" (31.8mm)
MaxFit3_5F8AP
