Model 108 FLEX-AUGER® Feed Delivery System

Auger Tube Installation

®
The FLEX-AUGER
used to make up the sloping portion of the auger line at the feed bin, and elsewhere in the system if necessary.
If additional elbows are required they should be ordered separately. Figure 2 shows how the elbow can be cut
into shorter sections.
Note: All measurements are along the outside edge of the elbow.
Note: PVC elbows are belled. Dimensions shown do not include bell.
MA1714C
Delivery System includes two 45 degree elbows as standard equipment. These elbows are
Dimension
"A"
"B"
"C"
"D" 50.3" (128 cm)
Figure 2.PVC Elbow Cutting Guidelines (Side View)
PVC Steel
16.8" (43 cm) 16.3" (41 cm)
25.2" (64 cm) 24.4" (62 cm)
33.6" (85 cm) 32.5" (83 cm)
48.8" (124 cm)
Installation
