Quick Start Tutorial: APT Mobile SureStreamer

B1.1.4 Edit the WAN Streams

WAN Streams #1 to #4 to and from the Internet
You must perform all changes described in section 4.3.3 on all four WAN streams.
Click on the WAN stream #1 to #4 and enter the parameter according to the table
below.
Parameter
MSSr ETH interface
Dest. IP Address
(hostnames)
Dest. IP Port
Diversity Generator
Table 8 shows Values for WAN Stream #1 to #4 for "Belfast Test."

B1.1.5 Apply the new profile to the SureStreamer

After all streams are edited, load this profile to make it the active profile.
Nothing else happens at this point. Only when the LUCI app on the iPhone sends data
via the LAN stream to the SureStreamer, the WAN streams are set up in the network.
Click on "Apply" to save and apply the new profile. It then appears under the head-
ing "Current Profile."
WAN #1 WAN #2
ETH0 ETH1
belfastsupport- belfastsupport-
eth0.ddns.net eth0.ddns.net
5006 5008
Off Level III
Page 46
WAN #3 WAN #4
ETH0 ETH1
belfastsupport- belfastsupport-
eth1.ddns.net eth1.ddns.net
5010 5012
Level III Off
