Quick Start Tutorial: APT Mobile SureStreamer
5.4. SureStreamVPN (client) – Mobile SureStreamer
Figure 5-5 shows the VPN Client configurations

5.4.1. Enable VPN (tick box)

Activate the VPN; now, the configurations of the SureStreamVPN option appear.

5.4.2. Compression (tick box)

Recommendation: Keep compression off for the first setup
!
This setting must be the same on the Client and Server

5.4.3. VPN Mode Selector

The dropdown box contains the supported VPN modes.
Select Client Mode.

5.4.4. Client LAN Interface

Select ETH2 as your LAN interface (optionally refer to Figure 5-3, page 33).

5.4.5. WAN Interfaces Selection

ETH0 and ETH1 are the WAN interfaces and are connected to the modems.
Select ETH0 as 1
st
interface and ETH1 as 2
Page 36
nd
interface.
