Quick Start Tutorial: APT Mobile SureStreamer

4.4.8. Create four Bi-directional Streams

First, create the four streams, as shown in the table.
These streams are complementary to the streams of the Mobile SureStreamer.
The numbers in parentheses correspond to the complementary WAN streams of the
SureStreamer.
Parameter
Type
1)
ETH interface
IP Address
IP Port
2)
Packet Size
3)
Rx Latency
4)
UPnP
5)
Ext. Port
Diversity Gen.
Table 3 shows the parameters of the streams #0 to #3
1)
In case there is only one Internet router, select the ETH interface connected to the In-
ternet for all streams.
2)
With packet size "Auto," the packet size is adapted to the selected audio algorithm.
Some formats allow you to adjust it if necessary (e.g., E-aptX).
3)
The latency of 150ms is the default value. If this value is too low, increase it (e.g., 300
ms)
4)
UPnP ON allows the auto-configuration of the Port Forwarding on your router. You
must enable UPnP on the router.
5)
The external port is the port that UPnP configures in the router. You can change it if
appropriate.
Stream #0 (1) Stream #1 (2)
Audio (RTP) Audio (RTP)
ETH0 ETH1
Sender Sender
5006 5008
Auto Auto
150 150
On On
5006 5008
Off Level III
Stream #2 (3)
Audio (RTP)
ETH0
Sender
5010
Auto
150
On
5010
Level III
Page 27
Stream #3 (4)
Audio (RTP)
ETH1
Sender
5012
Auto
150
On
5012
Off
