Attaching The Headrest - Leckey Squiggles Stander User Manual

Squiggles Stander User Manual p8
7.4 ATTACHING THE
HEADREST
To attach the Leckey headrest first open
the locking lever by pressing the safety
button and pulling the handle, then
remove the plastic insert from the
receiving collar. Then slide the stem
into the receiving bracket on the central
spine, set to the desired position and
secure using the locking handle.
The Whitmyer Lynx head support
attaches in the same way. To attach
the Whitmyer Pro-Series headsupports
remove the spacer collar from the
receiving bracket and lock the vertical
stem in position using the locking lever.
The product contains
components which could
present a choking hazard to
small children. Always check that
locking knobs and bolts within the
child's reach are tightened and secure
at all times.
7.5 INSERTING
ATTACHMENT BOLT
Insert the required attachement bolt
along with the retention plate (b). Place a
rubber lid C on, both, the top and
bottom of the sandal. Fasten using the
four screws D provided. To remove or
replace the attachment bolt, reverse this
process.
1
A
A
B
