Leckey Squiggles Stander User Manual page 7

7.1 FOLDING AND
UNFOLDING THE PIVOT
CHASSIS
The Pivot Chassis can be easily folded
for storage or transportation. To unfold,
release the levers
them together, rotate the rear tubes until
the levers engage in the locked position.
To fold the chassis simply reverse this
procedure.
Always remove the standing
support frame before trying to
fold the chassis.
Always use caution to ensure fingers
do not become trapped when folding
and unfolding the pivot chassis.
7.2 ATTACHING THE
STANDER TO ITS CHASSIS
The Squiggles Stander can be used as a
prone, supine or upright stander and has
been designed to fit with three chassis
options, the Mobile chassis, Pivot chassis
and the Easel chassis.
A shown by pressing
A
7.3 ATTACHING STANDER
TO PIVOT CHASSIS
To attach the stander to the Pivot
Chassis, pull the locking pin out, slide the
central spine into the receiving bracket
until it is fully engaged, release the pin
allowing it to snap back into place.
A
Squiggles Stander User Manual p7
